Proportional pressure regulator 0 to 6 bar G1/4 MPPES-3-1/4-6-010 - Festo 187337
Proportional pressure regulator for electrical pressure setting in the range 0 to 6 bar, setpoint 0 - 10 V. Port G1/4, max. pressure hysteresis 0.05 bar and degree of protection IP65. If the power supply cable is interrupted, the output pressure drops to 0 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The proportional pressure regulator MPPES-3-1/4-6-010 sets the output pressure electrically in the range 0 to 6 bar, specified via a 0 - 10 V setpoint signal. Pneumatically it is connected via G1/4. Design: piloted piston regulator.
Key benefits
- Fine pressure control: max. pressure hysteresis 0.05 bar
- Defined safety position: if the power supply cable is interrupted, the output pressure drops to 0 bar
- For harsh environments: degree of protection IP65, corrosion resistance class CRC 2
- PWIS conformity VDMA24364-B2-L for paint shops and sensitive processes
Operating conditions
The operating medium is compressed air to ISO 8573-1:2010 [7:4:4] and inert gas. Lubricated operation is possible but must then be continued. Mounting the MPPES-3-1/4-6-010: with through-hole, mounting position any. Permissible ambient temperature 0 to 50 °C. The MPPES-3-1/4-6-010 is connected electrically via 8-pin, M16x0.75, plug, to DIN 45326, round design.
Technical data
| Type | MPPES-3-1/4-6-010 |
|---|---|
| Festo part number | 187337 |
| Nominal size, supply | 7 mm |
| Nominal size, exhaust | 7 mm |
| Type of actuation | Electrical |
| Sealing principle | Soft |
| Mounting position | Any |
| Design | Piloted piston regulator |
| Short circuit current rating | For all electrical connections |
| Safety instructions | Safety position MPPES: if the power supply cable is interrupted, the output pressure drops to 0 bar. |
| Reverse polarity protection | For all electrical connections |
| Valve function | 3-way proportional-pressure regulator, closed |
| Operating pressure | 8 bar |
| Pressure regulation range | 0 to 6 bar |
| Inlet pressure 1 | 7 to 8 bar |
| Max. pressure hysteresis | 0.05 bar |
| Switching time off | 640 ms |
| Switching time on | 200 ms |
| Operational voltage range DC | 18 to 30 V |
| Nominal operating voltage DC | 24 V |
| Residual ripple | 10% |
| SETPOINT/ACTUAL values | Voltage type 0 - 10 V |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Approval | RCM |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | To EU EMC Directive, In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK RoHS instructions |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | 0 to 60 °C |
| Degree of protection | IP65 |
| Ambient temperature | 0 to 50 °C |
| Product weight | 1310 g |
| Electrical connection | 8-pin, M16x0.75, Plug, To DIN 45326, Round design |
| Type of mounting | With through-hole |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | G1/4 |
| Pneumatic connection, port 3 | G1/4 |
| Note on materials | RoHS compliant |
| Material housing | Wrought aluminium alloy |
| Material membrane | NBR |
| Weight | 1.4 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MPPES-3-1/4-6-010 |
| EAN | 4052568148058 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Thread | G 1/4 |
| Control range max. [bar] | 6 |
| Seal material | NBR |
| Medium | Compressed air, neutral gases |
| Function | 3-way proportional pressure regulating valve closed |
| Actuation type | Electrical |
| Druckregelbereich [bar] | 0 bis 6 |
| Medientemperatur [°C] | 0 bis 60 |
| Norm | DIN 45326 |
| Operating voltage | 24 V DC |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | G1/4 |
| Protection rating | IP65 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
