Proportional pressure regulator 0 to 10 bar G1/2 MPPES-3-1/2-PU-PO-420 - Festo 187735

Festo ✓ Original product Brand new

Proportional pressure regulator for electrical pressure setting in the range 0 to 10 bar, setpoint 4-20 mA. Port G1/2, max. pressure hysteresis 0.05 bar and degree of protection IP65. If the power supply cable is interrupted, the output pressure drops to 0 bar.

Net
€1,725.41
excl. VAT
Item FES-187735
Manufacturer no. MPPES-3-1/2-PU-PO-420
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo MPPES-3-1/2-PU-PO-420 regulates the output pressure in proportion to the 4-20 mA setpoint, pressure regulation range 0 to 10 bar. Pneumatically it is connected via G1/2. Design: piloted piston regulator.

Benefits at a glance

  • Fine pressure control: max. pressure hysteresis 0.05 bar
  • Defined safety position: if the power supply cable is interrupted, the output pressure drops to 0 bar
  • For harsh environments: degree of protection IP65, corrosion resistance class CRC 2
  • PWIS conformity VDMA24364-B2-L for paint shops and sensitive processes

Application and mounting

The operating medium is compressed air to ISO 8573-1:2010 [7:4:4] and inert gas. Lubricated operation is possible but must then be continued. Mounting the MPPES-3-1/2-PU-PO-420: with through-hole, mounting position any. Permissible ambient temperature 0 to 50 °C. Electrical connection of the MPPES-3-1/2-PU-PO-420: 8-pin, M16x0.75, plug, to DIN 45326, round design.

Technical data

TypeMPPES-3-1/2-PU-PO-420
Festo part number187735
Nominal size, supply11 mm
Nominal size, exhaust12 mm
Type of actuationElectrical
Sealing principleSoft
Mounting positionAny
DesignPiloted piston regulator
Short circuit current ratingFor all electrical connections
Safety instructionsSafety position MPPES: if the power supply cable is interrupted, the output pressure drops to 0 bar.
Reverse polarity protectionFor all electrical connections
Valve function3-way proportional-pressure regulator, closed
Operating pressure12 bar
Pressure regulation range0 to 10 bar
Inlet pressure 111 to 12 bar
Max. pressure hysteresis0.05 bar
Switching time off1000 ms
Switching time on230 ms
Operational voltage range DC18 to 30 V
Nominal operating voltage DC24 V
Residual ripple10%
SETPOINT/ACTUAL valuesCurrent type 4-20 mA
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4], Inert gas
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
ApprovalRCM
KC markKC-EMV
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Media temperature0 to 60 °C
Degree of protectionIP65
Ambient temperature0 to 50 °C
Product weight2670 g
Electrical connection8-pin, M16x0.75, Plug, To DIN 45326, Round design
Type of mountingWith through-hole
Pneumatic connection, port 1G1/2
Pneumatic connection, port 2G1/2
Pneumatic connection, port 3G1/2
Note on materialsRoHS compliant
Material housingWrought aluminium alloy
Material membraneNBR
Weight2.9 kg
ManufacturerFesto
Hersteller-NrMPPES-3-1/2-PU-PO-420
EAN4052568148201
Zolltarifnummer84811099
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
ThreadG 1/2
Control range max. [bar]10
Seal materialNBR
MediumCompressed air, neutral gases
Function3-way proportional pressure regulating valve closed
Inlet pressure max. [bar]12
Actuation typeElectrical
Druckregelbereich [bar]0 bis 10
Medientemperatur [°C]0 bis 60
NormDIN 45326
Operating voltage24 V DC
Betriebsdruck max [bar]12
Pneumatic connectionG1/2
Protection ratingIP65
Temperaturbereich0-50 °C
Temperature (max.)50
