Solenoid valve 3/2-way single solenoid, closed G1/4 MHE4-M1H-3/2G-1/4 - Festo 525186

Festo ✓ Original product Brand new

As a 3/2-way valve (single solenoid, closed), the Festo solenoid valve MHE4-M1H-3/2G-1/4 delivers 400 l/min standard nominal flow rate. Ratings: -0.9 to 8 bar operating pressure, G1/4 port and 18 mm width. Switching times 10.5 ms on and 5 ms off.

Net
€87.45
excl. VAT
Item FES-525186
Manufacturer no. MHE4-M1H-3/2G-1/4
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 400 l/min standard nominal flow rate, the solenoid valve MHE4-M1H-3/2G-1/4 switches as a 3/2-way valve (single solenoid, closed) at -0.9 to 8 bar operating pressure. Designed with G1/4 port, 18 mm width and 24 V DC operating voltage.

Key benefits

  • Flow: 400 l/min standard nominal flow rate at only 18 mm width
  • Pressure range: -0.9 to 8 bar, vacuum included
  • Switching times: 10.5 ms on, 5 ms off
  • Switching frequency: up to 120 Hz
  • Rugged: IP65 protection, corrosion resistance class 2
  • Temperature: -5 to 60 °C ambient

Applications

A switching frequency of up to 120 Hz suits fast cycling tasks such as blow-off or sorting. Mounting: with through-hole, grid dimension 24 mm. Operating medium for the MHE4-M1H-3/2G-1/4: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).

Technical data

TypeMHE4-M1H-3/2G-1/4
Festo part number525186
Valve function3/2-way, single solenoid, closed
Type of actuationelectrical
Width18 mm
Standard nominal flow rate400 l/min
pneumatic working portG1/4
Operating voltage24 V DC
Operating pressure-0.9 to 8 bar
Designpressure relief poppet valve
Reset methodmechanical spring
Degree of protectionIP65
Approvalc UL us - Recognised (Oil)
Nominal size4 mm
Grid dimension24 mm
Note on grid dimensionminimum distance between the valves is 6 mm
Exhaust-air functioncan be throttled
Sealing principlesoft
Mounting positionany
Manual overridenon-detenting
Type of pilotingdirect
Flow directionreversible with restrictions
Overlapnegative overlap
Operating pressure, reversible-0.9 to 1 bar
Max. switching frequency120 Hz
Switching time off5 ms
Switching time on10.5 ms
Duty cycle100%
Coil characteristics24 V DC: 5.6 W
Permissible voltage fluctuations± 10 %
Operating mediumcompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumlubricated operation possible (in which case lubricated operation will always be required)
Vibration resistancetransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Shock resistanceshock test with severity level 2 to FN 942017-5 and EN 60068-2-27
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Cleanroom suitability, measured according to ISO 14644-14class 6 according to ISO 14644-1
Media temperature-5 to 60 °C
Ambient temperature-5 to 60 °C
Product weight270 g
Electrical connection2-pin, plug
Type of mountingwith through-hole
Pneumatic connection, port 1G1/4
Pneumatic connection, port 2G1/4
Pneumatic connection, port 3G1/4
Note on materialsRoHS compliant
Material sealsHNBR, NBR
Material housingdie-cast zinc, coated
Material screwsgalvanised steel
Weight (shipping)0.28 kg
Weight0.28 kg
ManufacturerFesto
Hersteller-NrMHE4-M1H-3/2G-1/4
EAN4052568161514
Zolltarifnummer84812090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/4
Nominal size DN [mm]4
Seal materialHNBR, NBR
MediumCompressed air
Function3/2 closed monostable
Flow rate [l/min]400
Actuation typeElectrical
SeriesMHE4
Betriebsdruck max [bar]8
Pneumatic connectionG1/4
Protection ratingIP65
Temperaturbereich-5-60 °C
