Solenoid valve 3/2-way single solenoid, closed G1/8 MHE3-MS1H-3/2G-1/8 - Festo 525147
As a 3/2-way valve (single solenoid, closed), the Festo solenoid valve MHE3-MS1H-3/2G-1/8 delivers 200 l/min standard nominal flow rate. Ratings: -0.9 to 8 bar operating pressure, G1/8 port and 14 mm width. Switching times 2.3 ms on and 2.8 ms off.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With 200 l/min standard nominal flow rate, the solenoid valve MHE3-MS1H-3/2G-1/8 switches as a 3/2-way valve (single solenoid, closed) at -0.9 to 8 bar operating pressure. Designed with G1/8 port, 14 mm width and 24 V DC operating voltage.
Benefits at a glance
- Flow: 200 l/min standard nominal flow rate at only 14 mm width
- Pressure range: -0.9 to 8 bar, vacuum included
- Switching times: 2.3 ms on, 2.8 ms off
- Switching frequency: up to 280 Hz
- Rugged: IP65 protection, corrosion resistance class 2
- Temperature: -5 to 60 °C ambient
Applications
A switching frequency of up to 280 Hz suits fast cycling tasks such as blow-off or sorting. Mounting: with through-hole, grid dimension 19 mm. Operating medium for the MHE3-MS1H-3/2G-1/8: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).
Technical data
| Type | MHE3-MS1H-3/2G-1/8 |
|---|---|
| Festo part number | 525147 |
| Valve function | 3/2-way, single solenoid, closed |
| Type of actuation | electrical |
| Width | 14 mm |
| Standard nominal flow rate | 200 l/min |
| pneumatic working port | G1/8 |
| Operating voltage | 24 V DC |
| Operating pressure | -0.9 to 8 bar |
| Design | pressure relief poppet valve |
| Reset method | mechanical spring |
| Degree of protection | IP65 |
| Approval | RCM, c UL us - Recognised (Oil) |
| CE mark (see declaration of conformity) | to EU EMC Directive, in accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | to UK RoHS regulations |
| Nominal size | 3 mm |
| Grid dimension | 19 mm |
| Note on grid dimension | minimum distance between the valves is 5 mm |
| Exhaust-air function | can be throttled |
| Sealing principle | soft |
| Mounting position | any |
| Manual override | non-detenting |
| Type of piloting | direct |
| Flow direction | reversible with restrictions |
| Overlap | negative overlap |
| Reverse polarity protection | bipolar |
| Additional functions | protective circuit |
| Operating pressure, reversible | -0.9 to 1 bar |
| Max. switching frequency | 280 Hz |
| Switching time off | 2.8 ms |
| Switching time on | 2.3 ms |
| Tolerance switching time off | +10 %/-50 % |
| Tolerance switching time on | +10%/-30% |
| Switching time dispersion from 1 Hz | 0.2 ms |
| Duty cycle | 100% |
| Coil characteristics | 24 V DC: low-current phase 1.6 W, high-current phase 6.5 W |
| Permissible voltage fluctuations | ± 10 % |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation possible (in which case lubricated operation will always be required) |
| Vibration resistance | transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Restrictions for environmental and media temperature | as a function of switching frequency (see graph) |
| Shock resistance | shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | class 6 according to ISO 14644-1 |
| Media temperature | -5 to 60 °C |
| Ambient temperature | -5 to 60 °C |
| Product weight | 120 g |
| Electrical connection | 2-pin, plug |
| Type of mounting | with through-hole |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Note on materials | RoHS compliant |
| Material seals | HNBR, NBR |
| Material housing | die-cast zinc, coated |
| Material screws | galvanised steel |
| Weight (shipping) | 0.145 kg |
| Weight | 0.145 kg |
| Manufacturer | Festo |
| Hersteller-Nr | MHE3-MS1H-3/2G-1/8 |
| EAN | 4052568161316 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/8 |
| Nominal size DN [mm] | 3 |
| Seal material | HNBR, NBR |
| Medium | Compressed air |
| Function | 3/2 closed monostable |
| Flow rate [l/min] | 200 |
| Actuation type | Electrical |
| Series | MHE3 |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | G1/8 |
| Protection rating | IP65 |
| Temperaturbereich | -5-60 °C |
