Brass mini ball valve G 1/8" female thread / male thread, PN 15

When used as a brass mini ball valve, the article shuts off the flow in the line with a quarter turn. The article is listed with thread G 1/8" (male thread) and version female thread / male thread. The material is chrome-plated brass. The seals are made of PTFE / FKM.

Benefits

• full bore in the open position and therefore low pressure loss, verified by thread G 1/8" (male thread)
• pressure rating PN -0.98 to 15 bar
• material chrome-plated brass as stated in the data
• sealing material PTFE / FKM
• temperature range -20 to +90 °C
• version female thread / male thread

Applications

The article is called for in pipework, compressed air networks and plant construction. The listed media are water, neutral gaseous and non-aggressive liquid media, mineral oils, compressed air, vacuum.
