5/2-way solenoid valve, 5/2-way with air spring return (monostable), Sub-base valve, 24 V DC

This 5/2-way solenoid valve controls the air path in a compressed air system. The switching function is 5/2-way with air spring return (monostable). The operating pressure is stated as 1.5 to 8 bar (5/3-way: 2 to 8 bar) bar. The materials are body and spool aluminium, seals NBR, pilot plastic.

Advantages

• Switching function 5/2-way with air spring return (monostable), so the rest position is clearly defined.
• Control with 24 V DC at a power consumption of 0.8 W / valve solenoid, which relieves the supply when many valves share one cabinet.
• Switching time of below 15 ms, max. 5 switching cycles / sec. (5/3-way: max. 3 switching cycles / sec.), suitable for short machine cycles.
• Operating pressure of 1.5 to 8 bar (5/3-way: 2 to 8 bar) bar, which fixes the permissible working range.
• Materials body and spool aluminium, seals NBR, pilot plastic, matched to the intended service.

Applications

• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
• Replacement of a defective valve of the same type in existing machines.
• Control of double-acting cylinders with an air demand up to 700 l/min.
