Dual 3/2-way solenoid valve NC/NO, SV series, manifold mount size 2, 24 V DC - E.MC

Name: Dual 3/2-way solenoid valve NC/NO, SV series, manifold mount size 2, 24 V DC - E.MC
Brand: E.MC
SKU: FL-588631
Price: 84.01 EUR
Availability: InStock

E.MC ✓ Original product Brand new

Two 3/2-way functions on one station of the SV series valve terminal, size 2, with ports in the manifold base. Switching logic NC/NO, flow 700 l/min. Screws and gasket are included, the valve bolts straight onto a free valve station.

Net

€84.01

excl. VAT

Item FL-588631

Manufacturer no. SVM 5422-U

Question about this item

Datasheet (PDF) 2 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

One output blocks without a signal, the other is open. With this NC/NO combination two opposing 3/2-way functions occupy just one valve station. The slice delivers 700 l/min at 0.8 W per coil on a size 2 valve station.

Advantages

Working ports sit in the manifold base, so the tubing stays connected when the valve is swapped.
Just 0.8 W per solenoid at 24 V DC, which keeps the power budget low on fully populated terminals.
Response time of 20 ms or less at 5 bar and up to 5 cycles per second.
Aluminium body and spool with NBR seals, rated for at least 40 million cycles.
LED status indicator and manual override make commissioning and troubleshooting easier.

Applications

Controlling two single-acting cylinders from one valve station
Blow-off air, vacuum generators or gripper functions with separate outputs
Space-saving extension of a fully populated SV series valve terminal

Technical data

Feature	Value
Design	Valve slice for SV series valve terminal, ports in the manifold base
Function	2 x 3/2-way, NC/NO (one normally closed, one normally open)
Size	2 (G 1/8)
Flow rate	700 l/min
Operating pressure	2 to 8 bar
Proof pressure	12 bar
Medium	clean compressed air, filtered to 40 µm, no lubrication required
Temperature range	-20 to 70 °C, non-freezing
Operating voltage	24 V DC, tolerance ±10 %
Power consumption	0.8 W per solenoid
Number of solenoids	2
Insulation class	F
Protection class	IP40
Response time at 5 bar	max. 20 ms
Max. switching frequency	5 cycles/s
Service life	min. 40 million cycles
Materials	body and spool aluminium, seals NBR, pilot section plastic
Indicator	LED status indicator
Mounting	2 screws on the valve station, tightening torque 0.15 to 0.18 Nm
Scope of delivery	valve with screws and gasket
Weight	120 g
Dimension drawing	in the E.MC datasheet (PDF)
Manufacturer	E.MC
Hersteller-Nr	SVM 5422-U
EAN	4050571917050
Zolltarifnummer	84812090
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	Anschlussplattenventil
Flow rate [l/min]	700
