This replacement solenoid coil works with 230 V AC and draws 26 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3.
Solenoid coil, 230 V AC, coil form C1, plug size 3, 26 VA, 49 x 55 x 60
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€196.30
Item
FL-743272
Manufacturer no.
MAG C1 230V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MAG C1 230V
EAN4050571957346
Customs tariff number85059029
ConditionNew
Artikel
FL-743272
Frequently Bought Together
-
This Item:
€196.30
-
Valve terminal, 8 stations, CC-Link, outlets M 5 at valves (top), 16x M 5, 24 V DC
€1,300.60
-
5/3-way solenoid valve, centre position closed, G 1/4", 24 V DC, 850 l/min, nominal size 4.8 mm, 3 W
€162.25
Total price
A burnt out solenoid coil stops a whole valve even though the valve body is sound. This replacement coil works with 230 V AC and draws 26 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3. The dimensions are 49 x 55 x 60.
Advantages
- Control voltage 230 V AC, matching the existing supply.
- Power consumption of 26 VA at 100 percent duty cycle.
- Plug size 3, so the existing valve plug still fits.
- Outside dimensions 49 x 55 x 60, so the space above the valve is known.
- Armature hole spacing of 55 mm, so the coil sits positively on the armature.
Technical data
| Feature | Value |
|---|---|
| Design | C1 |
| Control voltage | 230 V AC |
| Connector size | 3 |
| Power | 26 VA |
| External dimension [mm] | 49 x 55 x 60 |
| Distance between anchor holes L [mm] | 55 |
| Anchor holes bottom D1 [mm] | 19.5 |
| Anchor holes top D2 [mm] | 12.1 |
| Duty cycle | 100% duty cycle |
| Scope of delivery | Solenoid coil incl. connector or cable |
Applications
- Valves with a valve plug of size 3.
- Maintenance of plants in continuous operation.
- Keeping a spare part in the workshop store.
- Replacement of a defective coil on solenoid valves with 230 V AC.
| Weight | 0.500000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | MAG C1 230V |
| EAN | 4050571957346 |
| Zolltarifnummer | 85059029 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | C1 |
| Power | 26 VA |
