This replacement solenoid coil works with 115 V AC and draws 28 - 29 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3.
Solenoid coil, 115 V AC, coil form C, plug size 3, 28 - 29 VA, 36 x 54 x 53
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€154.03
Item
FL-131810
Manufacturer no.
MAG C 115V
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MAG C 115V
EAN4050571473280
Customs tariff number85059029
ConditionNew
Artikel
FL-131810
Frequently Bought Together
-
This Item:
€154.03
-
5/2-way solenoid valve, Impulse valve, G 1/4", 115 V AC, 980 l/min, 1.5 to 10 bar, exhaust G 1/8"
€87.29
-
Valve terminal, 4 stations, PROFIBUS, outlets G 1/8" at base plate (side), 8x G 1/8", 24 V DC
€1,233.17
Total price
A burnt out solenoid coil stops a whole valve even though the valve body is sound. This replacement coil works with 115 V AC and draws 28 - 29 VA. It is rated for 100 percent duty cycle and is supplied including plug or cable. The plug size is 3. The dimensions are 36 x 54 x 53.
Advantages
- Plug size 3, so the existing valve plug still fits.
- Outside dimensions 36 x 54 x 53, so the space above the valve is known.
- Armature hole spacing of 51 mm, so the coil sits positively on the armature.
- Coil form C, which makes the assignment to the valve unambiguous.
- Control voltage 115 V AC, matching the existing supply.
Technical data
| Feature | Value |
|---|---|
| Design | C |
| Control voltage | 115 V AC |
| Connector size | 3 |
| Power | 28 - 29 VA |
| External dimension [mm] | 36 x 54 x 53 |
| Distance between anchor holes L [mm] | 51 |
| Anchor holes bottom D1 [mm] | 18.3 |
| Anchor holes top D2 [mm] | 12.2 |
| Counterbore top D4 [mm] | 22.3 |
| Duty cycle | 100% duty cycle |
| Scope of delivery | Solenoid coil incl. connector or cable |
Applications
- Keeping a spare part in the workshop store.
- Replacement of a defective coil on solenoid valves with 115 V AC.
- Valves with a valve plug of size 3.
- Maintenance of plants in continuous operation.
| Weight | 0.340000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | MAG C 115V |
| EAN | 4050571473280 |
| Zolltarifnummer | 85059029 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Bauform | C |
| Power | 28 - 29 VA |
