LAN/WiFi thermometer STE2 R2, 20-pack, each with 3 m temperature sensor and power adapter, 2 DI, PoE - HW group 600837

Rolling out environmental monitoring across many sites is easier with identical units that arrive complete. This pack holds 20 STE2 R2 devices, each with its own temperature sensor and power adapter, and each unit monitors up to 5 sensor values on two RJ11 ports.

Benefits

• No extra parts for rollout: every one of the 20 units ships with a 3 m IP67 temperature sensor and a power adapter with EU, UK and US plugs.
• Choice of network link: 10/100 Mbit Ethernet or IEEE 802.11b/g/n WiFi, with optional PoE power at 60 mA.
• Expandable per site: up to 5 values from daisy-chained 1-Wire UNI sensors such as humidity, CO2 or 4-20 mA.
• Direct detector inputs: 2 digital inputs per unit for dry contacts such as door or flood detectors.
• Central overview: SNMP and XML for existing monitoring systems, plus the free HWg-cloud.com portal for up to 20 devices per user account.

Technical data

Applications

• Standardized temperature monitoring in server rooms across distributed sites
• Alerts on air conditioning failure in technical rooms
• Leak detection with flood detectors or a WLD relay, for example under raised floors or at liquid cooling installations
• Food and pharmaceutical storage

Scope of delivery

• 20x STE2 R2, each in retail package
• 20x temperature sensor with 3 m cable (IP67), one per unit
• 20x power adapter with EU, UK and US plugs, one per unit

Compatibility

• HW group 1-Wire UNI sensors: temperature (indoor, outdoor, cryo, calibrated), humidity, CO2 and VOC, light, AC/DC current, AC voltage 0-230 V, 4-20 mA converter
• Detectors: water flood, WLD relay with sensing cable, airflow, door contact, PIR motion, gas leak, mains presence 110/230 V, vibration
• SMS-GW3 and SMS-GW3 LTE gateways, HWg-cloud.com and SensDesk portals, HWg Monitor app
