Listed as a solvent cement socket ball valve, this version shuts off the flow in the line with a quarter turn. Key figures are flow rate 190 l/min together with inside diameter D 20 mm.
Solvent cement socket ball valve, PVC-U / EPDM, 20 mm (water version)
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€22.60
Item
FL-068372
Manufacturer no.
PVCKH 20 WASSER
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.PVCKH 20 WASSER
EAN4050571556952
Customs tariff number39174000
ConditionNew
Artikel
FL-068372
Frequently Bought Together
-
This Item:
€22.60
-
Check valve 12 L (M18x1.5), cracking pressure 0.2 bar, zinc-plated steel
€36.47
-
PVC diaphragm valve (manual) PVC / FKM, Rp 2" female thread, DN 50
€745.39
Total price
This item shuts off the flow in the line with a quarter turn and is listed as a solvent cement socket ball valve. The data sheet states flow rate 190 l/min as well as inside diameter D 20 mm. The material is PVC-U. For the seals the data gives EPDM.
Benefits
- material PVC-U as stated in the data
- sealing material EPDM
- inside diameter D 20 mm
- temperature range 0 to +60 °C
- full bore in the open position and therefore low pressure loss, verified by flow rate 190 l/min
Technical data
| seals | EPDM |
|---|---|
| inside diameter D [mm] | 20 |
| nominal size DN [mm] | 15 |
| dimension H [mm] | 80 |
| dimension L [mm] | 16.0 |
| dimension Z [mm] | 48 |
| dimension E [mm] | 49 |
| dimension B [mm] | 50 |
| dimension C [mm] | 64 |
| flow rate [l/min] | 190 |
| material | PVC-U |
| temperature range | 0 to +60 °C |
Applications
The version is applied in pipework, compressed air networks and plant construction.
| Weight | 0.120000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | PVCKH 20 WASSER |
| EAN | 4050571556952 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Flow rate [l/min] | 190 |
| Dichtungen | EPDM |
