This item shuts off the flow in the line with a quarter turn and is listed as a butterfly valve with female thread. The defining values are thread G Rp 4" and pressure rating PN 0 - 16 bar.
Butterfly valve with female thread Rp 4", 0 - 16 bar, nickel-plated brass
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€578.02
Item
FL-040214
Manufacturer no.
KLM 40 MSV
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.KLM 40 MSV
EAN4050571434151
Customs tariff number84818085
ConditionNew
Artikel
FL-040214
Frequently Bought Together
-
This Item:
€578.02
-
High-pressure ball valve, stainless steel, G 4", 0 - 50 bar, DN 100
€6,073.92
-
PVC-U ball valve, pneumatic actuator, DN 32, spring closing, solvent socket, FKM seal
€349.04
Total price
Installed in the line, this butterfly valve with female thread shuts off the flow in the line with a quarter turn. Selection is based on thread G Rp 4" and pressure rating PN 0 - 16 bar. It is manufactured from nickel-plated brass. The stated sealing material is PTFE / EPDM.
Benefits
- full bore in the open position and therefore low pressure loss, verified by thread G Rp 4"
- pressure rating PN 0 - 16 bar
- material nickel-plated brass as stated in the data
- sealing material PTFE / EPDM
- temperature range -10 to +130 °C
Technical data
| thread G | Rp 4" |
|---|---|
| nominal size DN [mm] | 100 |
| dimension L [mm] | 146 |
| pressure rating PN [bar] | 0 - 16 |
| dimension H [mm] | 145.0 |
| dimension R [mm] | 205 |
| material | nickel-plated brass |
| sealing material | PTFE / EPDM |
| temperature range | -10 to +130 °C |
| media | flüssige and gasförmige neutrale Medien Vorteile gegenüber Kugelhähnen or |
Applications
The article is used in pipework, compressed air networks and plant construction. According to the data sheet flüssige and gasförmige neutrale Medien Vorteile gegenüber Kugelhähnen or are approved.
| Weight | 6.000000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | KLM 40 MSV |
| EAN | 4050571434151 |
| Zolltarifnummer | 84818085 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
