ISOLine ISO 15552 standard cylinder, double-acting, 125 mm bore, 320 mm stroke, G1/2, up to 150 °C, magnetic piston - Norgren TRA/802125/M/320
The Norgren TRA/802125/M/320 is a double-acting standard cylinder with 125 mm bore and 320 mm stroke that delivers a theoretical 7363 N at 6 bar. The TRA/802125/M/320 runs from 1 to 16 bar at -20 to 150 °C, port G1/2. Cylinder switches detect the magnetic piston of the TRA/802125/M/320 without contact.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 125 mm bore the Norgren TRA/802125/M/320 produces a theoretical 7363 N at 6 bar over 320 mm of stroke.
Benefits in use
- The TRA/802125/M/320 follows ISO 15552 and is interchangeable with other ISO 15552 cylinders of 125 mm bore.
- The TRA/802125/M/320 has a magnetic piston, cylinder switches sense its position over 320 mm of stroke without mechanical contact.
- The Adaptive Cushioning System (ACS) handles end-position cushioning on the TRA/802125/M/320 with 125 mm bore.
- The TRA/802125/M/320 operates from 1 to 16 bar with a 125 mm bore.
- The TRA/802125/M/320 is rated for -20 to 150 °C, piston seal in fluoroelastomer (FKM).
- The TRA/802125/M/320 has a barrel in anodised aluminium and a piston rod in martensitic stainless steel with male thread.
Applications
Typical tasks for the TRA/802125/M/320 are lifting, pushing and feed tasks in machine and plant building, sized for 320 mm of stroke.
Standards
Mounting dimensions of the TRA/802125/M/320 comply with ISO 15552, VDMA 24562 applies as well.
Technical data
| Manufacturer part number | TRA/802125/M/320 |
|---|---|
| Product line | ISOLine |
| Series | TRA/802000/M |
| Standard | ISO 15552 |
| Function | double-acting |
| Bore | 125 mm |
| Stroke | 320 mm |
| Port | G1/2 |
| Theoretical force at 6 bar | 7363 N |
| Operating pressure | 1 to 16 bar |
| Medium | compressed air |
| Temperature range | -20 to 150 °C |
| Cushioning | Adaptive Cushioning System (ACS) |
| Magnetic piston | yes |
| Barrel | anodised aluminium |
| Piston rod | stainless steel (martensitic) |
| Piston rod thread | male thread |
| Piston seal | fluoroelastomer (FKM) |
| Piston rod seal | fluoroelastomer (FKM) |
| RoHS | compliant |
| Customs tariff number | 84123100 |
| Manufacturer | Norgren |
| Hersteller-Nr | TRA/802125/M/320 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 125 |
| Stroke [mm] | 320 |
| Seal material | FKM |
| Housing material | Aluminium, anodised |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/2 |
| Temperaturbereich | -20-150 °C |
| Temperature (max.) | 150 |
