ISOLine profile cylinder with position sensor ISO 15552, double-acting, 100 mm bore, 400 mm stroke, G1/2 - Norgren PSA/802100/F1/400
4710 N theoretical force at 6 bar from a 100 mm bore and 400 mm stroke: a double-acting profile cylinder for pushing, lifting and clamping. The PSA/802100/F1/400 operates from 1 to 12 bar across -20 to 80 °C. On the PSA/802100/F1/400: an integrated position sensor reports the piston position as an absolute analogue signal.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
4710 N at 6 bar over 400 mm of stroke: that is what the Norgren PSA/802100/F1/400 achieves with its 100 mm piston.
Benefits
- The PSA/802100/F1/400 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
- The PSA/802100/F1/400 works at 1 to 12 bar and -20 to 80 °C.
- The PSA/802100/F1/400 reports the piston position via a position sensor with analogue signal.
- Materials on the PSA/802100/F1/400: barrel in anodised aluminium, rod in stainless steel (austenitic).
- Piston in non-magnetic version on the PSA/802100/F1/400.
Applications
Typical locations for the PSA/802100/F1/400 are fixtures, feeding systems and special machines, where 400 mm of stroke and 4710 N are needed.
Standards and compliance
The dimensions of the PSA/802100/F1/400 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version PSA/802100/F1/400 is not RoHS compliant, under REACH it contains an SVHC substance. The PSA/802100/F1/400 is not subject to the WEEE directive.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | PSA/802100/F1/400 |
| Product line | ISOLine |
| Series | PSA/802000/F1 |
| Design | profile cylinder |
| Standard | ISO 15552, VDMA 24562, NFE 49-003-1 |
| Operating mode | double-acting |
| Bore | 100 mm |
| Stroke | 400 mm |
| Version code | F1 |
| Port size | G1/2 |
| Theoretical force at 6 bar | 4710 N |
| Operating pressure | 1 to 12 bar |
| Medium | compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | no cushioning |
| Piston | non-magnetic |
| Position measuring | position sensor, absolute analogue signal, resistance potentiometer |
| Cylinder barrel | anodised aluminium |
| Piston rod material | stainless steel (austenitic) |
| Piston rod thread | male thread |
| Piston seal | polyurethane (PU) |
| Piston rod seal | polyurethane (PU) |
| Country of origin | Germany |
| RoHS | not compliant |
| REACH | contains an SVHC substance |
| WEEE | not subject to WEEE |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Hersteller-Nr | PSA/802100/F1/400 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend |
| Bauform | Profilzylinder |
| Piston Ø [mm] | 100 |
| Stroke [mm] | 400 |
| Seal material | PU |
| Housing material | Aluminium, anodised |
| Function | double-acting |
| Norm | ISO 15552, VDMA 24562 |
| Betriebsdruck max [bar] | 12 |
| Pneumatic connection | G1/2 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
