ISOLine profile cylinder, double acting, 32 mm bore, 400 mm stroke - Norgren PRA/802032/M/400

The double acting ISOLine profile cylinder Norgren PRA/802032/M/400 has a piston diameter of 32 mm with 400 mm stroke and reaches a theoretical force of 482 N.

Benefits

• Conforms to ISO 15552, VDMA 24562 and NFE 49-003-1
• High stiffness and consistent behaviour over service life
• Polyurethane seals for low friction operation and long life
• Switches mount flush with the profile barrel
• Theoretical force 482 N at 32 mm piston diameter
• Stroke 400 mm at an operating pressure of 1 to 12 bar
• Barrel made of anodised aluminium, piston rod made of martensitic stainless steel
• Temperature range -20 to 80 °C, cushioning adaptive cushioning system acs

Applications

It is used in assembly machines, packaging lines and handling units that need 400 mm of stroke and 482 N.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The cylinder conforms to ISO 15552. VDMA 24562 and NFE 49-003-1 therefore apply as well. The piston seal is made of Polyurethane (PU).
