ISOLine tie-rod cylinder ISO 15552, double-acting, 80 mm bore, 200 mm stroke, G3/8, up to 150 °C, magnetic piston - Norgren TRA/802080/M/200

Norgren ✓ Original product Brand new

The double-acting tie-rod cylinder Norgren TRA/802080/M/200 with 80 mm bore and 200 mm stroke delivers a theoretical 3016 N at 6 bar. The TRA/802080/M/200 operates from 1 to 16 bar across -20 to 150 °C and has a magnetic piston for cylinder switches. On the TRA/802080/M/200: mounting dimensions follow ISO 15552, end positions are cushioned by the Adaptive Cushioning System (ACS).

Net
€426.77
excl. VAT
Item NRG-TRA/802080/M/200
Manufacturer no. TRA/802080/M/200
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

3016 N at 6 bar over 200 mm of stroke: that is what the Norgren TRA/802080/M/200 achieves with its 80 mm piston.

Benefits

  • The TRA/802080/M/200 complies with the mounting dimensions of ISO 15552, VDMA 24562 and NFE 49-003-1.
  • ACS cushions the end positions of the TRA/802080/M/200.
  • On the TRA/802080/M/200 cylinder switches detect the magnetic piston without contact.
  • The TRA/802080/M/200 works at 1 to 16 bar and -20 to 150 °C.
  • Materials on the TRA/802080/M/200: barrel in anodised aluminium, rod in stainless steel (martensitic).

Applications

Fields of use for the TRA/802080/M/200: fixtures, feeding systems and special machines, where 200 mm of stroke and 3016 N are needed.

Standards and compliance

The dimensions of the TRA/802080/M/200 conform to ISO 15552, so VDMA 24562 and NFE 49-003-1 apply as well. Version TRA/802080/M/200 is RoHS compliant, under REACH it contains no SVHC substances. The TRA/802080/M/200 is not subject to the WEEE directive.

Technical data

ManufacturerNorgren
Manufacturer part numberTRA/802080/M/200
Product lineISOLine
SeriesTRA/802000/M
Designtie-rod cylinder
StandardISO 15552, VDMA 24562, NFE 49-003-1
Operating modedouble-acting
Bore80 mm
Stroke200 mm
Version codeM
Port sizeG3/8
Theoretical force at 6 bar3016 N
Operating pressure1 to 16 bar
Mediumcompressed air
Temperature range-20 to 150 °C
CushioningAdaptive Cushioning System (ACS)
Pistonmagnetic
Cylinder barrelanodised aluminium
Piston rod materialstainless steel (martensitic)
Piston rod threadmale thread
Piston sealfluoroelastomer (FKM)
Piston rod sealfluoroelastomer (FKM)
Weight4.1 kg
Country of originGermany
RoHScompliant
REACHno SVHC substances
WEEEnot subject to WEEE
Customs tariff number84123100
ECLASS51010101
Hersteller-NrTRA/802080/M/200
Zolltarifnummer84123100
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Ausführungdoppeltwirkend
BauformZugankerzylinder
Piston Ø [mm]80
Stroke [mm]200
Seal materialFKM
Housing materialAluminium, anodised
Functiondouble-acting
NormISO 15552, VDMA 24562
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-20-150 °C
Temperature (max.)150
