Solenoid actuated flange valve, 32 mm nominal diameter, 2/2 NC, 230 V AC, cast steel - Norgren 8303500.9151.23050

With a body of cast steel and seals of Nitrile rubber (NBR) Norgren 8303500.9151.23050 switches gases and liquids in the range 0.1 to 16 bar.

Benefits

• High flow rate
• Damped operation
• Compact and functional design
• Operating pressure 0.1 to 16 bar in function 2/2 NC
• Kv value 23 m³/h and Cv value 26.6 gpm
• Seal material Nitrile rubber (NBR) for fluid temperatures of -10 to 90 °C

Applications

Typical installations are cooling circuits, washing and filling plants and gas lines with fluid temperatures of -10 to 90 °C.

Standards and conformity

The version is RoHS compliant, an SVHC substance is present under REACH. The product falls under the WEEE directive. The electrical connection follows DIN EN 175301-803 form A. The housing reaches protection class IP65.
