Solenoid actuated 3/2-way safety valve, G1, 24 V DC, XSz 32 series - Norgren 2493130080002400

Name: Solenoid actuated 3/2-way safety valve, G1, 24 V DC, XSz 32 series - Norgren 2493130080002400
Brand: Norgren
SKU: NRG-2493130080002400
Price: 4809.54 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The Norgren 2493130080002400 solenoid actuated 3/2-way safety valve has G1 / G1 1/2 ports and a 24 V DC coil. Safety valves of this type pressurise the downstream air circuit only when enabled and exhaust it on shut-off, including the 2493130080002400. For the 2493130080002400, flow is 7333 l/min, exhaust flow 23000 l/min, the pressure range is 2 to 8 bar.

Net

€4,809.54

excl. VAT

Item NRG-2493130080002400

Manufacturer no. 2493130080002400

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren 2493130080002400 is a solenoid actuated 3/2-way safety valve from the Herion range in the XSz 32 series with G1 / G1 1/2 ports and a 24 V DC coil for compressed air.

Benefits

High flow: 7333 l/min through G1 (G1, 24 V DC).
Fast venting: 23000 l/min exhaust flow (G1, 24 V DC).
Service life: B10 value of 6 million cycles (G1, 24 V DC).
IP65 protection for use in the machine environment (G1, 24 V DC).
Works at 2 to 8 bar operating pressure (G1, 24 V DC).
Usable at -10 to 60 °C ambient temperature (G1, 24 V DC).

Applications

Safety valves are used in machines whose pneumatic actuators must be depressurised on emergency stop or when a guard is opened, for example with the 2493130080002400.

Ordering note

Order under Norgren number 2493130080002400, so the part matches the existing installation without cross-referencing.

Technical data

Manufacturer	Norgren
Manufacturer part number	2493130080002400
Product type	3/2-way safety valve
Product line	Herion
Series	XSz 32
Valve function	3/2, normally closed (NC)
Actuation	solenoid pilot, spring return
Design	seat valve
Port	G1 / G1 1/2
Voltage	24 V DC
Power consumption	16 W
Electrical connection	DIN EN 175301-803 Form A
Coil code	0800
Protection class	IP65
Medium	compressed air
Operating pressure	2 to 8 bar
Temperature	-10 to 60 °C
Flow	7333 l/min
Exhaust flow	23000 l/min
Body	die-cast aluminium
Seals	PU (polyurethane)
B10 value	6 million cycles
Weight	8 kg
Shelf life	3 years
RoHS	compliant
Customs tariff number	84814010
Feature	double valve system, inherently fail-safe without residual pressure
Feature	for pneumatic clutch and brake systems and other 3-way safety functions
Feature	fast exhaust capability
Feature	complies with Machinery Directive 2006/42/EC, ISO 13849 and ISO 16092, DGUV certified
Feature	quick adjustment of the overlap on mechanical presses
Feature	no additional electrical monitoring required
Hersteller-Nr	2493130080002400
Zolltarifnummer	84814010
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	magnetbetätigt
Seal material	PU
Housing material	Die-cast aluminium
Function	3/2 NC
Actuation type	Electrical
Operating voltage	24 V DC
Betriebsdruck max [bar]	8
Pneumatic connection	G1
Protection rating	IP65
Temperaturbereich	-10-60 °C
