Pneumatic parallel gripper for HRC size 16, stroke per jaw 8 mm HPPH-16-16-NC-N-SR12 - Festo 8205392
With 139 to 151 N gripping force per jaw when closing at 6 bar, the parallel gripper HPPH-16-16-NC-N-SR12 holds prismatic and round parts. 8 mm stroke per jaw, repetition accuracy 0.06 mm, double-acting, ball guide. Runs on 2.5 to 7 bar via push-in connector for 4 mm O.D..
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The size 16 parallel gripper HPPH-16-16-NC-N-SR12 delivers 139 to 151 N gripping force per jaw when closing at 6 bar. Both jaws move parallel towards each other. Version HPPH-16-16-NC-N-SR12: double-acting, ball guide, rack and pinion, flat finger mounting.
Benefits
- 139 to 151 N gripping force per jaw when closing at 6 bar, total gripping force 278 to 302 N
- Repetition accuracy 0.06 mm
- 8 mm stroke per jaw, with max. 100 g per external gripper finger
- Closing time from 90 ms, opening time from 180 ms at 6 bar, operating frequency 1 Hz
- For HRC: gripping force 116 to 128 N per jaw at 2.5 to 5 bar, certificate TÜV Süd M70132770525.01
- Gripping force retention when closing
Applications
Typical tasks for the HPPH-16-16-NC-N-SR12 are assembly, feeding and pick-and-place in automated systems, at -5 to 50 °C ambient temperature. Gripper fingers are mounted on the jaws, each external finger may weigh up to 100 g. Integrated displacement encoder for position detection. For human-robot collaboration Festo recommends a workpiece weight of 1 kg. Shipping weight 0.8 kg.
Technical data
| Size | 16 |
|---|---|
| Total stroke | 16 mm |
| Stroke per gripper jaw | 8 mm |
| Max. angular gripper jaw backlash ax, ay | 0° |
| Max. gripper jaw backlash Sz | 0 mm |
| Repetition accuracy, gripper | 0.06 mm |
| Number of gripper jaws | 2 |
| Drive system | Pneumatic |
| Mounting position | Any |
| Mode of operation | Double-acting |
| Cushioning | At one end, Not adjustable |
| Gripper function | Parallel |
| Gripping force retention | During closing |
| Design | Flat mounting method for gripper fingers, Guidance, Rack and pinion, With gripper finger, Pneumatic gripper, Positively driven motion sequence |
| Guide | Ball guide |
| Position detection | Via integrated displacement encoder |
| Switching status indication | Blue LED, switching status via signal input |
| Operating pressure | 2.5 to 7 bar |
| Operating pressure HRC | 2.5 to 5 bar |
| Max. operating frequency of gripper | 1 Hz |
| Min. opening time at 6 bar | 180 ms |
| Min. closing time at 6 bar | 90 ms |
| Max. mass per external gripper finger | 100 g |
| Max. current consumption | 100 mA |
| Nominal operating voltage DC | 24 V |
| Switching output | PNP |
| Switching input | NPN |
| Permissible voltage fluctuations | ±10% |
| Approval | RCM |
| CE mark (see declaration of conformity) | To EU EMC Directive, In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMC, To UK RoHS instructions |
| Certificate issuing authority | TÜV Süd M70132770525.01 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating medium | Lubricated operation possible, after that always operate lubricated |
| Shock resistance | Shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Vibration resistance | Transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Relative air humidity | 0 - 90%, Non-condensing |
| Sound pressure level | 75 dB(A) |
| Degree of protection | IP40 |
| Ambient temperature | -5 to 50 °C |
| Total gripping force, closing at 6 bar | 278 to 302 N |
| Gripping force per gripper jaw, closing at 6 bar | 139 to 151 N |
| Total gripping force HRC, closing | 232 to 256 N |
| Gripping force per gripper jaw HRC, closing | 116 to 128 N |
| Note on gripping force | Dependent on the stroke, With integrated compression spring |
| Theoretical spring force per gripper jaw, closing | 23.3 to 34.9 N |
| Mass moment of inertia | 0.6 kgcm² |
| Max. force on gripper jaw Fz static | 176 N |
| Max. moment Mx | 2.8 Nm |
| Max. moment My | 1.4 Nm |
| Max. moment Mz | 1.4 Nm |
| Bending radius, fixed cable | 26 mm |
| Bending radius, moving cable | 52 mm |
| Maintenance interval | Lifetime lubrication |
| Product weight | 680 g |
| Recommended workpiece weight for MRK | 1 kg |
| Electrical connection 1, function | Field device side |
| Electrical connection 1, connection type | Cable with socket |
| Electrical connection 1, cable outlet | Angled |
| Electrical connection 1, design | Round |
| Electrical connection 1, connector system | M8x1, A-coded, to EN 61076-2-104 |
| Electrical connection 1, number of connections/cores | 8 |
| Electrical connection 1, used connections/cores | 6 |
| Electrical connection 1, connection pattern | 997559 |
| Electrical connection 1, tightening torque | 0.2 Nm |
| Type of mounting | With mounting kit, To ISO 9409 |
| Pneumatic connection | For push-in connector O.D. 4 mm |
| Note on materials | RoHS compliant |
| Cover material | Reinforced PA |
| Material spring | High-alloy stainless steel |
| Housing material | Anodised wrought aluminium alloy |
| Gripper jaw material | High-alloy steel |
| Material piston | Wrought aluminium alloy, anodised |
| Piston seal material | TPE-U(PU) |
| O-ring material | HNBR, NBR |
| Screw material | Galvanised steel, High-alloy steel |
| Gear wheel material | High-alloy steel |
| Gripper finger material | Wrought aluminium alloy, anodised |
| Weight | 0.8 kg |
| Manufacturer | Festo |
| Hersteller-Nr | HPPH-16-16-NC-N-SR12 |
| EAN | 4052568651831 |
| Zolltarifnummer | 84798997 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Medium | Compressed air |
| Function | double-acting |
| Actuation type | pneumatic |
| Betriebsdruck max [bar] | 7 |
| Protection rating | IP40 |
| Temperature (max.) | 50 |
