Flat Cylinder DZH, metric
Festo flat cylinders DZH in metric version are double-acting cylinders with a flat profile and adjustable pneumatic end-position cushioning (PPV). The flat design reduces height in confined installation situations. The category covers more than 70 items.
The type designation states bore and stroke, for example DZH-20-100 for 20 mm bore and 100 mm stroke. DZH flat cylinders are used for rotation-secured linear movements with low height.
- 73 items
- 1 manufacturer
- Net prices plus VAT
Buying guide
How to choose Flat Cylinder DZH, metric
What matters when choosing: properties, comparison and typical applications.
Typical Applications
DZH flat cylinders suit handling and assembly tasks with limited building height. The adjustable end-position cushioning allows a smooth deceleration at higher speeds or masses.
Features
Flat profile low height for confined installation
End cushioning adjustable pneumatic (PPV)
Double-acting active extend and retract
Metric bore and stroke values in millimetres
