Tube union, straight design, tube stud 22 L, second tube stud 22 L, stainless steel 1.4571

The tube union connects a tube stud 22 L and a second tube stud 22 L. The operating pressure reaches up to 160 bar. The straight design carries the medium through the part without deflection.

Benefits

• With tube stud 22 L the size is fixed, so no reworking of the line is required
• The operating pressure up to 160 bar is released for this size
• The temperature range from -20 °C to +200 °C covers cold installation and warm machine surroundings
• The material stainless steel 1.4571 stays resistant without additional coating in the range from -20 °C to +200 °C

Technical data

Applications

Hydraulic lines in machine and plant engineering, pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
