The tube fitting saves an intermediate construction because the male thread M 5 and a tube of 6x4 mm meet directly. Tube 6x4 mm, straight design, material nickel plated brass.
Tube fitting, straight design, male thread M 5, tube 6x4 mm, nickel plated brass
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€1.06
Item
FL-001676
Manufacturer no.
CK 54 MSV
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.CK 54 MSV
EAN4050571234454
Customs tariff number74122000
ConditionNew
Artikel
FL-001676
Frequently Bought Together
-
This Item:
€1.06
-
Push-in fitting, elbow design, male thread R 3/8", tube 8 mm, nickel plated brass, seal NBR
€5.00
-
OT-RAUFOSS 6237800 von Kongsberg Raufoss
€7.57
Total price
The tube fitting accepts the male thread M 5 and a tube of 6x4 mm. The part clamps the tube with union nut and clamping ring. The operating pressure reaches from -0.95 bar to 20 bar. The straight design carries the medium through the part without deflection.
Benefits
- The temperature range from -20 °C to +80 °C covers cold installation and warm machine surroundings
- Nickel plated brass as material covers the released range from -20 °C to +80 °C
- The seals in NBR are matched to the medium
- Union nut and clamping ring allow the joint to be released repeatedly
Technical data
| Material | nickel plated brass |
|---|---|
| Seals | NBR |
| Male thread | M 5 |
| Tube diameter (outside x inside) | 6x4 mm |
| Operating pressure | -0.95 to 20 bar |
| Temperature range | -20 to +80 °C |
Applications
Plant construction with frequent modification, tube lines in pneumatics, water lines on machines, laboratory equipment and dosing technology.
| Weight | 0.007200 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | CK 54 MSV |
| EAN | 4050571234454 |
| Zolltarifnummer | 74122000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Nickel-plated brass |
| Einschraubgewinde | M 5 |
| Schlauchdurchmesser (außen x innen) [mm] | 6x4 |
| Dichtungen | NBR |
| Temperaturbereich | -20-80 °C |
