Tube fitting, straight design, for metal braided hose, male thread G 1/8", tube 7x4 mm, aluminium

The tube fitting accepts the male thread G 1/8" and a tube of 7x4 mm. The part clamps the tube with union nut and clamping ring. The material is aluminium. The straight design carries the medium through the part without deflection.

Benefits

• Union nut and clamping ring allow the joint to be released repeatedly
• The size 7x4 is clearly assigned and stays available for reordering
• The connection over male thread G 1/8" is fixed in size and needs no adaptor
• With tube 7x4 mm the size is fixed, so no reworking of the line is required

Applications

Plant construction with frequent modification, tube lines in pneumatics, water lines on machines, laboratory equipment and dosing technology.

Standards and conformity

The following approvals are documented for the materials used: FDA.
