This cylinder switch reports the position of the magnetic piston from the T-slot of the cylinder without contact. A key figure is the operating voltage 10 - 30 V (DC). Dimension sensor type fully electronic sensor, reverse polarity and short circuit protected, with a yellow LED, connecting lead 2 mtr., 3x 0,12 mm².
Cylinder switch for a 5 mm T-slot, fully electronic sensor, yellow LED, lead 2 m
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€89.36
Item
FL-041773
Manufacturer no.
ZSB 33
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.ZSB 33
EAN4050571817190
Customs tariff number85365019
ConditionNew
Artikel
FL-041773
Frequently Bought Together
-
This Item:
€89.36
-
Cable with M8 coupling, 4-wire, 5 m, straight
€11.27
-
Cylinder switches, Fully electronic sensor (reverse polarity protection), green LED
€33.55
Total price
As a cylinder switch the article reports the position of the magnetic piston from the T-slot of the cylinder without contact. The data state the operating voltage 10 - 30 V (DC).
Benefits
- Operating voltage 10 - 30 V (DC) with the switching function normally open contacts (PNP).
- Connecting lead 2 mtr., 3x 0,12 mm².
- Temperature range -30 to +70 °C, protection class IP 67.
- Temperature range of -30 to +70 °C as per the data sheet.
- Listed with Lead length 2 m.
Technical data
| Sensor type | fully electronic sensor, reverse polarity and short circuit protected, with a yellow LED |
|---|---|
| Operating voltage | 10 - 30 V (DC) |
| Switching function | normally open contacts (PNP) |
| Maximum switching current | 100 mA |
| Maximum power | 6 W |
| Connecting lead | 2 mtr., 3x 0,12 mm² |
| Temperature range [°C] | -30 to +70 |
| Protection class | IP 67 |
| Sensor design | fully electronic sensor |
| Status indicator | yellow LED |
| Lead length [m] | 2 |
Applications
The cylinder switch is used wherever it has to report the piston position from the T-slot without contact.
| Hersteller-Nr | ZSB 33 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571817190 |
| Weight | 0.033000 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
