This cylinder switch reports the position of the magnetic piston from the T-slot of the cylinder without contact. What counts here is the operating voltage 10 - 230 V (AC), 10 - 170 V (DC). The listed size is sensor type two-wire reed sensor with a yellow LED, connecting lead 3 mtr., 2x 0,14 mm².
Cylinder switch for a 5 mm T-slot, two-wire reed sensor, yellow LED, lead 3 m
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€25.61
Item
FL-029966
Manufacturer no.
ZSA 12
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.ZSA 12
EAN4050571816902
Customs tariff number85365019
ConditionNew
Artikel
FL-029966
Frequently Bought Together
-
This Item:
€25.61
-
Inductive proximity switch, M 12x1, sensing distance 4 mm, non-flush mounting, a 2 m cable
€53.09
-
Fixing clamps for ZSC (Tie rod Ø (32 - 63) mm)
€10.56
Total price
The cylinder switch reports the position of the magnetic piston from the T-slot of the cylinder without contact. The data give sensor type two-wire reed sensor with a yellow LED and connecting lead 3 mtr., 2x 0,14 mm².
Benefits
- Operating voltage 10 - 230 V (AC), 10 - 170 V (DC) with the switching function normally open contact.
- Maximum switching current 150 mA and maximum power 10 W / VA.
- Connecting lead 3 mtr., 2x 0,14 mm².
- Temperature range -20 to +70 °C, protection class IP 67.
- Listed with Max. switching current 150 mA.
Technical data
| Sensor type | two-wire reed sensor with a yellow LED |
|---|---|
| Operating voltage | 10 - 230 V (AC), 10 - 170 V (DC) |
| Switching function | normally open contact |
| Max. switching current [mA] | 150 |
| Maximum power | 10 W / VA |
| Connecting lead | 3 mtr., 2x 0,14 mm² |
| Protection class | IP 67 |
| Temperature range [°C] | -20 to +70 |
| Sensor design | two-wire reed sensor |
| Status indicator | yellow LED |
| Lead length [m] | 3 |
Applications
Typical use is anywhere the cylinder switch has to report the piston position from the T-slot without contact.
| Hersteller-Nr | ZSA 12 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571816902 |
| Weight | 0.046000 |
| Zolltarifnummer | 85365019 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
