Bellows suction cup for vacuum handling, Ø 14 mm, stroke 10 mm, silicone, 65 Shore A
The bellows suction cup holds the workpiece on the suction face by vacuum. The underlying rating is a suction cup diameter of 14 mm. Ø 14 mm, stroke 10 mm, holder type F, colour red in silicone, 65 Shore A.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Once installed, the bellows suction cup holds the workpiece on the suction face by vacuum. This version is listed with suction cup diameter 14 mm, stroke 10 mm, holder type F and colour red. Its rating is a suction cup diameter of 14 mm.
Benefits
- Listed with Suction cup diameter D Ø 14 mm.
- Stroke 10 mm.
- Dimension D1 of 5 mm as per the data sheet.
- Listed with Dimension D2 12 mm.
- Dimension D3 6 mm.
Applications
Typical use is anywhere the bellows suction cup has to pick up and hold workpieces by vacuum.
Technical data
| Material | silicone, 65 Shore A |
|---|---|
| Suction cup diameter D [mm] | Ø 14 |
| Stroke [mm] | 10 |
| Colour | red |
| Connection (female thread) | G 1/8" |
| Connection (male thread) | G 1/8" |
| Dimension D1 [mm] | 5 |
| Dimension D2 [mm] | 12 |
| Dimension D3 [mm] | 6 |
| Dimension h [mm] | 23 |
| Suction cup height H [mm] | 35 |
| Temperature range [°C] | -40 to +200 |
| Holder type | F |
| Bellows form | 2.5 folds |
| Weight | 0.002 kg |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | VS 14 B2 SI |
| EAN | 4050571724092 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
