This vacuum ejector produces the handling vacuum from compressed air on the venturi principle. What counts here is a suction rate of 160 l/min. The dimensions come to vacuum port G 1/2", suction rate 160 l/min.
Multi-stage vacuum ejector, vacuum port G 1/2", suction rate 160 l/min
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€1,101.00 €925.21
Item
FL-015963
Manufacturer no.
VHP 5
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.VHP 5
EAN4050571719524
Customs tariff number84141089
ConditionNew
Artikel
FL-015963
Frequently Bought Together
- This Item: €1,101.00 €925.21
- Oval suction cup for vacuum handling, suction area 36 x 12 mm, stroke 2 mm, silicone, 60 Shore A €24.51 €20.60
- Oval suction cup for vacuum handling, suction area 60 x 20 mm, stroke 3 mm, silicone, 60 Shore A €27.02 €22.71
The vacuum ejector produces the handling vacuum from compressed air on the venturi principle. This version is listed with vacuum port G 1/2" and suction rate 160 l/min. Decisive for the selection is a suction rate of 160 l/min.
Benefits
- Suction rate 160 l/min.
- Air consumption of 120 l/min as per the data sheet.
- Listed with Height H 32 mm.
- Temperature range of -10 to +100 °C as per the data sheet.
Technical data
| Suction rate [l/min] | 160 |
|---|---|
| Compressed air thread | G 1/4" |
| Vacuum thread | G 1/2" |
| Exhaust thread | G 1/2" |
| Air consumption [l/min] | 120 |
| Height H [mm] | 32 |
| Nozzle material | brass |
| Seals | Neopren |
| Temperature range [°C] | -10 to +100 |
Applications
Typical use is anywhere the vacuum ejector has to produce a vacuum from compressed air.
| Hersteller-Nr | VHP 5 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571719524 |
| Weight | 0.750000 |
| Zolltarifnummer | 84141089 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
