The flat suction cup holds the workpiece on the suction face by vacuum. The underlying rating is a suction cup diameter of 70 mm. Ø 70 mm, stroke 6 mm, holder type M, colour reddish brown in SBR (50A).
Flat suction cup, Ø 70 mm, stroke 6 mm, SBR (50A), reddish brown, fine lip
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€29.77
€25.02
Item
FL-228702
Manufacturer no.
VS 70 FF SBR
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS 70 FF SBR
EAN4050571725426
Customs tariff number84879090
ConditionNew
Artikel
FL-228702
Frequently Bought Together
-
This Item:
€29.77 €25.02
-
3/2-way vacuum valve, port G 3/8", nominal width DN 11 mm, control voltage 230 V AC
€1,361.24 €1,143.90
-
2/2-way vacuum valve, port G 3/8", nominal width DN 10 mm, control voltage 24 V DC
€213.49 €179.40
In use, the flat suction cup holds the workpiece on the suction face by vacuum. The data also state a stroke of 6 mm. This version comes with suction cup diameter 70 mm, stroke 6 mm, holder type M and colour reddish brown.
Benefits
- Suction cup diameter D of Ø 70 mm as per the data sheet.
- Listed with Stroke 6 mm.
- Listed with Dimension D3 50 mm.
- Dimension D4 33.0 mm.
- Dimension h of 30.0 mm as per the data sheet.
Technical data
| Material | SBR (50A) |
|---|---|
| Suction cup diameter D [mm] | Ø 70 |
| Stroke [mm] | 6 |
| Colour | reddish brown |
| Connection (female thread) | G 1/4" |
| Dimension D3 [mm] | 50 |
| Dimension D4 [mm] | 33.0 |
| Dimension h [mm] | 30.0 |
| Height including holder [mm] | 32 |
| Dimension h3 [mm] | 17.0 |
| Dimension h4 [mm] | 3.5 |
| Temperature range [°C] | -30 to +80 |
| Holder type | M |
| Suction cup version | fine lip |
Applications
Typical use is anywhere the flat suction cup has to pick up and hold workpieces by vacuum.
| Hersteller-Nr | VS 70 FF SBR |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571725426 |
| Weight | 0.044000 |
| Zolltarifnummer | 84879090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
