This swivel eye mounting holds the cylinder and carries its forces into the machine frame. A key figure is a piston diameter of 63 mm. Size 190 x 75 x 16 mm, material aluminium.
Spherical swivel eye mounting ISO 15552, for piston diameter 63 mm, aluminium
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€62.67 €52.66
Item
FL-029991
Manufacturer no.
TE 63 ALU
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.TE 63 ALU
EAN4050571693275
Customs tariff number84129080
ConditionNew
Artikel
FL-029991
Frequently Bought Together
- This Item: €62.67 €52.66
- Spherical swivel eye mounting ISO 15552, for piston diameter 100 mm, aluminium €108.79 €91.42
- Spherical swivel eye mounting ISO 15552, for piston diameter 32 mm, stainless steel 1.4401 €129.97 €109.22
As a swivel eye mounting the article holds the cylinder and carries its forces into the machine frame. The data state a piston diameter of 63 mm. This version is listed with 190 mm for dimension L, 75 mm for dimension M and 16 mm for dimension D. Material aluminium is listed for this version.
Benefits
- Designed for cylinders with a 63 mm piston diameter to ISO 15552.
- Interface dimensions to ISO 15552 allow a replacement without changing the machine.
- Material aluminium for size 63 mm.
- Dimension L comes to 190 mm for size 63 mm.
- Dimension D comes to 16 mm for size 63 mm.
Technical data
| Material | aluminium |
|---|---|
| For piston diameter [mm] | 63 |
| Dimension A [mm] | 21 |
| Dimension B [mm] | 15.0 |
| Dimension D [mm] | 16 |
| Dimension F [mm] | 32 |
| Dimension L [mm] | 190 |
| Dimension M [mm] | 75 |
| Dimension N [mm] | 56.5 |
| Scope of delivery | 1 swivel mounting incl. 4 fixing screws |
Applications
On feed and infeed units the spherical swivel eye mounting carries the cylinder of size 63 mm.
Standards and conformity
Made to ISO 15552 and matched to a piston diameter of 63 mm.
| Hersteller-Nr | TE 63 ALU |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571693275 |
| Weight | 0.300000 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
