Precision vacuum regulator G 3/4", -1 to 0,7 bar
Precision vacuum regulator G 3/4", -1 to 0,7 bar
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€3,655.09
€3,071.50
excl. Shipping Cost
Available
Fast shipping
Item
FL-067773
Manufacturer no.
RP 34 VU
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RP 34 VU
EAN4050571604394
Customs tariff number90328100
ConditionNeu
Artikel
FL-067773
Frequently Bought Together
-
This Item:
€3,655.09 €3,071.50excl. Shipping Cost
-
Suction cup fixations, Type L, G 1/8" (IG)
€8.70 €7.31excl. Shipping Cost
-
Mounting clamp for FIQS vacuum filter
€6.74 €5.66excl. Shipping Cost
Application:
These vacuum regulators allow precise pressure regulation in the vacuum and overpressure range. They provide the facility to regulate the vacuum as a bypass or in shut-off technology:
1. Bypass adjustment*: This adjustment should be used, if an existing vacuum must be reduced by delivering compressed air. Recommended for adjusting large vacuum quantities. 2. Stop adjustment*: The vacuum is pulled and adjusted by the regulator. Once the desired value is reached, the regulator is closed. Recommended to save energy.
Materials:
Body: Aluminium die-casting, internal parts: stainless steel/brass, diaphragms: NBR
Temperature range:
-40 to +90 °C
Input pressure:
max. 17 bar
Pressure gauge connection:
G 1/4"
Control accuracy:
± 2.5 mbar
These vacuum regulators allow precise pressure regulation in the vacuum and overpressure range. They provide the facility to regulate the vacuum as a bypass or in shut-off technology:
1. Bypass adjustment*: This adjustment should be used, if an existing vacuum must be reduced by delivering compressed air. Recommended for adjusting large vacuum quantities. 2. Stop adjustment*: The vacuum is pulled and adjusted by the regulator. Once the desired value is reached, the regulator is closed. Recommended to save energy.
Materials:
Body: Aluminium die-casting, internal parts: stainless steel/brass, diaphragms: NBR
Temperature range:
-40 to +90 °C
Input pressure:
max. 17 bar
Pressure gauge connection:
G 1/4"
Control accuracy:
± 2.5 mbar
| Thread | G 3/4" |
| Suction performance [m³/h] | 48,0 |
| Suction performance [l/min] | 800 |
| Pressure gauge connection | G 1/4" |
| Pressure regulation range [bar] | -1 to 0.7 |
| D [mm] | 115 |
| L [mm] | 87 |
| H [mm] | 238 |
| Mounting brackets | RP 34 VU W |
| Hersteller-Nr | RP 34 VU |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571604394 |
| Weight | 24.000000 |
| Zolltarifnummer | 90328100 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
