Vacuum regulator without external leakage G 1" - Fluidics equipment R 10 VU

Application:
A vacuum without external leakage can be accurately regulated with these vacuum regulators. They are used in vacuum systems where individual consumer units need to be supplied with different levels of vacuum.

Adjustment:
The configuration is carried out using a knurled screw or via a pneumatic signal.

Materials:
Body: Anodized aluminium, seals: NBR

Temperature range:
-10 to +80 °C

Pressure gauge connection:
G 1/4" (controller G 1/4" and G 3/8": G 1/8")

Control connection (pneumatic setting):
G 1/8" (controller G 1 1/2": G 1/4")

Version	Standard controller
Setting	Manually
Thread	G 1"
Suction performance [m³/h]	80
Suction performance [l/min]	1333
Pressure gauge connection	G 1/4"
Pressure regulation range [bar]	-1 to -0,2
