In service the bellows suction cup holds the workpiece on the suction face by vacuum. The decisive figure is a suction cup diameter of 14 mm. Dimensions Ø 14 mm, stroke 10 mm, holder type F, colour black, made of NBR (60A).
Bellows suction cup for vacuum handling, Ø 14 mm, stroke 10 mm, NBR (60A)
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€3.79
Item
FL-228778
Manufacturer no.
VS 14 B2 NBR
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.VS 14 B2 NBR
EAN4050571724078
Customs tariff number84879090
ConditionNew
Artikel
FL-228778
Frequently Bought Together
-
This Item:
€3.79
-
3/2-way vacuum valve, port G 1/2", nominal width DN 11 mm, control voltage 24 V DC
€1,143.90
-
Free-flow silencer for exhaust air, port G 1/2", diameter 38 mm, length 75 mm
€55.43
Total price
This bellows suction cup holds the workpiece on the suction face by vacuum. The stated material is NBR (60A). The data state a suction cup diameter of 14 mm.
Benefits
- Listed with Suction cup diameter D Ø 14 mm.
- Stroke 10 mm.
- Dimension D1 of 5 mm as per the data sheet.
- Listed with Dimension D2 12 mm.
- Dimension D3 6 mm.
Technical data
| Material | NBR (60A) |
|---|---|
| Suction cup diameter D [mm] | Ø 14 |
| Stroke [mm] | 10 |
| Colour | black |
| Connection (female thread) | G 1/8" |
| Connection (male thread) | G 1/8" |
| Dimension D1 [mm] | 5 |
| Dimension D2 [mm] | 12 |
| Dimension D3 [mm] | 6 |
| Dimension h [mm] | 23 |
| Suction cup height H [mm] | 35 |
| Temperature range [°C] | -30 to +90 |
| Holder type | F |
| Bellows form | 2.5 folds |
