Double-acting short-stroke cylinder, bore 25 mm, stroke 30 mm, without magnetic piston, G 1/8 - Fluidics equipment
With only 30 mm stroke this double-acting short-stroke cylinder with 25 mm bore delivers a calculated 295 N push force at 6 bar. The version without magnetic piston is sufficient where no position sensing is needed. Operating pressure up to 10 bar, NBR seals for -20 to +80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 25 mm bore and 30 mm stroke this short-stroke cylinder is built for short, powerful movements. The calculated push force is 295 N at 6 bar and 491 N at the maximum of 10 bar.
Why this cylinder
- Pneumatic force in both directions, 295 N push force at 6 bar (calculated)
- Stainless steel 1.4305 piston rod with M 5 thread
- NBR seals for -20 to +80 °C
- Rated up to 10 bar, G 1/8 port
Dimensions
The dimension letters refer to the dimensional drawing of the series.
| Dimension A | 44.5 mm |
|---|---|
| Dimension B | 40 mm |
| Dimension D | 10 mm |
| Dimension F | 5.8 mm |
| Dimension G | 9.0 mm |
| Dimension H | 24.5 mm |
| Dimension I | 26 mm |
| Dimension J | 10.5 mm |
| Dimension L | 28.5 mm |
| Dimension M | 15.5 mm |
| Dimension N | 28.0 mm |
| Dimension O | 14.0 mm |
| Dimension Q | 5.7 mm |
| Dimension R | 5.7 mm |
| Dimension S | 42.0 mm |
| Dimension T | 10 mm |
| Dimension V | 8 mm |
| Dimension W | 5.5 mm |
| Dimension X | 22 mm |
| Dimension Y | 11 mm |
| Dimension Z | 15 mm |
| Dimension AA | 5.5 mm |
| Dimension AB | 8 mm |
Applications
Short-stroke cylinders of this size suit clamping, stopping, ejecting and embossing in fixtures where only 30 mm of travel is needed and space is tight. The 295 N is a theoretical value, piston area times pressure, without friction.
Technical data
| Type | short-stroke cylinder |
|---|---|
| Function | double-acting |
| Bore | 25 mm |
| Stroke | 30 mm |
| Version | without magnetic piston |
| Piston rod thread C1 | M 5 |
| Compressed air port P | G 1/8 |
| Operating pressure | max. 10 bar |
| Temperature range | -20 to +80 °C |
| Head and base plate | anodised aluminium / brass |
| Cylinder tube | anodised aluminium |
| Piston rod | 1.4305 |
| Seal | NBR |
| Cylinder switch type | G |
| Piston area (calculated) | 4.9 cm² |
| Push force at 6 bar (calculated) | 295 N |
| Push force at 10 bar (calculated) | 491 N |
| Weight | 185 g |
| Customs tariff number | 84799070 |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | ND 25/30 |
| EAN | 4050571523060 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | ohne Magnetkolben |
| Bauform | Kurzhubzylinder |
| Piston Ø [mm] | 25 |
| Stroke [mm] | 30 |
| Seal material | NBR |
| Housing material | Aluminium, anodised |
| Medium | Compressed air |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/8 |
| Temperaturbereich | -20-80 °C |
| Temperature (max.) | 80 |
