Yoke, with bolts, external male thread M 8, zinc plated steel

Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.

The clevis head links the piston rod to the load through clevis and pin. The underlying rating is the piston rod thread M 8. The dimensions come to 57 x 20 x 22 mm.

Clevis head with pin and male thread, for piston rod thread M 8

Name: Clevis head with pin and male thread, for piston rod thread M 8
Brand: Fluidics equipment
SKU: FL-045854
Price: 18.88 EUR
Availability: InStock

FLUIDICS EQUIPMENT Original product

Net price (excl. VAT)

€18.88

Item FL-045854

Manufacturer no. GAKA M8

Personal expert advice

Brand new Specialist dealer since 2009 Original product Worldwide shipping

Product data

Manufacturer no.GAKA M8

EAN4050571314545

Customs tariff number73181595

ConditionNew

Artikel

FL-045854

Frequently Bought Together

This Item: Clevis head with pin and male thread, for piston rod thread M 8
€18.88
Rod end, for piston rod thread M 6, zinc-plated steel, dimension D 6 mm
€15.41
Flexible coupling, for piston rod thread M 10, zinc-plated steel
€35.15

Total price

Details

Once installed, the clevis head links the piston rod to the load through clevis and pin. Decisive for the selection is the piston rod thread M 8.

Benefits

Fits the piston rod thread M 8.
Dimension GL comes to 20 mm.
Dimension F comes to 57 mm.
Dimension D comes to 22 mm.
Dimension B of 16 mm as per the data sheet.

Technical data

For piston rod thread A	M 8
Dimension B [mm]	16
Dimension C [mm]	47
Dimension D [mm]	22
Dimension E [mm]	8
Dimension F [mm]	57
Dimension G [mm]	16
Dimension H [mm]	8
Dimension GL [mm]	20

Applications

In feed and clamping equipment the clevis head sits on thread M 8.

Information

More Information
Hersteller-Nr	GAKA M8
Manufacturer	Fluidics equipment
EAN	4050571314545
Weight	0.047000
Zolltarifnummer	73181595
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität	Original product
Artikelzustand	New
