Yoke with bolts M 10, Zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
This clevis head links the piston rod to the load through clevis and pin. What counts here is the piston rod thread M 10. Material zinc-plated steel, size 52 x 40 x 28 mm.

Clevis head with pin, for piston rod thread M 10, zinc-plated steel

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€7.95
Item FL-004521
Manufacturer no. GAK M10
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.GAK M10
EAN4050571314637
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-004521

The clevis head links the piston rod to the load through clevis and pin. The stated figure is the piston rod thread M 10.

Benefits

  • Fits the piston rod thread M 10.
  • Material zinc-plated steel for piston rod thread M 10.
  • Dimension F comes to 52 mm.
  • Dimension D comes to 28 mm.
  • Dimension C comes to 40 mm.

Technical data

Materialzinc-plated steel
For piston rod thread AM 10
Dimension B [mm]20
Dimension C [mm]40
Dimension D [mm]28
Dimension E [mm]10
Dimension F [mm]52
Dimension G [mm]20
Dimension H [mm]10

Applications

In feed and clamping equipment the clevis head sits on thread M 10.

More Information
Hersteller-Nr GAK M10
Manufacturer Fluidics equipment
EAN 4050571314637
Weight 0.090000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
