The rod end links the piston rod to the load so that it can pivot. The underlying rating is the piston rod thread M 8. 8 x 54 x 42 mm in zinc-plated steel.
Rod end, for piston rod thread M 8, zinc-plated steel, dimension D 8 mm, dimension L 54 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€18.93 €15.91
Item
FL-043841
Manufacturer no.
SGSA M8
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.SGSA M8
EAN4050571625474
Customs tariff number73269098
ConditionNew
Artikel
FL-043841
Frequently Bought Together
- This Item: €18.93 €15.91
- Rod end, for piston rod thread M 12, stainless steel, dimension D 12 mm, dimension L 22 mm €49.68 €41.75
- Flexible coupling, for piston rod thread M 12x1.25, 1.4305, dimension D 77.0 mm €128.10 €107.65
Once installed, the rod end links the piston rod to the load so that it can pivot. This version is listed with 8 mm for dimension D, 54 mm for dimension L and 42 mm for dimension H. The stated figure is the piston rod thread M 8.
Benefits
- Fits the piston rod thread M 8.
- Material zinc-plated steel for piston rod thread M 8.
- Dimension D comes to 8 mm.
- Dimension L comes to 54 mm.
- Dimension C comes to 9.00 mm.
Technical data
| Material | zinc-plated steel |
|---|---|
| For piston rod thread A | M 8 |
| Dimension B [mm] | 12 |
| Dimension C [mm] | 9.00 |
| Dimension D [mm] | 8 |
| Dimension D2 [mm] | 24 |
| Dimension H [mm] | 42 |
| Dimension L [mm] | 54 |
| Dimension GL [mm] | 25 |
Applications
In feed and clamping equipment the rod end sits on thread M 8.
| Hersteller-Nr | SGSA M8 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571625474 |
| Weight | 0.037000 |
| Zolltarifnummer | 73269098 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
