Yoke with bolts M 27x2, Zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
This clevis head links the piston rod to the load through clevis and pin. What counts here is the piston rod thread M 27x2. Material zinc-plated steel, size 148 x 110 x 72 mm.

Clevis head with pin, for piston rod thread M 27x2, zinc-plated steel

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€70.49
Item FL-004525
Manufacturer no. GAK 125
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.GAK 125
EAN4050571314316
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-004525
Frequently Bought Together
Total price

Once installed, the clevis head links the piston rod to the load through clevis and pin. It is supplied with 148 mm for dimension F, 110 mm for dimension C and 72 mm for dimension D. The article is made of zinc-plated steel.

Benefits

  • Fits the piston rod thread M 27x2.
  • Material zinc-plated steel for piston rod thread M 27x2.
  • Dimension F comes to 148 mm.
  • Dimension D comes to 72 mm.
  • Dimension C comes to 110 mm.

Technical data

Materialzinc-plated steel
For piston rod thread AM 27x2
Dimension B [mm]55
Dimension C [mm]110
Dimension D [mm]72
Dimension E [mm]30
Dimension F [mm]148
Dimension G [mm]55
Dimension H [mm]30

Applications

In feed and clamping equipment the clevis head sits on thread M 27x2.

More Information
Hersteller-Nr GAK 125
Manufacturer Fluidics equipment
EAN 4050571314316
Weight 1.800000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
