5/2-way solenoid valve, 5/2-way (spring return*), 3x G 1/4", 24 V DC, 1000 l/min, 1.5 to 8 bar

This 5/2-way solenoid valve switches the air path electrically and needs no manual action at the machine. The connection is 3x G 1/4" and control is by 24 V DC. The switching function is 5/2-way (spring return*). The operating pressure is stated as 1.5 to 8 bar. The materials are body aluminium, seals NBR.

Advantages

• Protection class IP 65 (connector size 1) at the solenoid coil, suitable for dusty surroundings.
• Temperature range of -5 to +50 °C, which covers use in the machine room as well as outdoors.
• Connection 3x G 1/4" and exhaust 2x G 1/4", so the piping follows the existing line network.
• Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
• Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.

Applications

• Installation in control cabinets with a supply of 24 V DC.
• Control of pneumatic flaps, gates and diverters in conveying equipment.
• Cycled feeding and clamping units in fixture building.
• Plants operated within the temperature range -5 to +50 °C.
