5/3-way pneumatic valve, centre position closed, G 1/4", 600 l/min, nominal size 3.9 mm
This 5/3-way pneumatic valve controls compressed air through connection G 1/4". The switching function is centre position closed. The materials are body and spool aluminium, seals NBR, pilot polyamide.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
In purely pneumatic control systems a pilot-operated valve does the job of a relay. This 5/3-way pneumatic valve switches with a pilot pressure of 2 to 8 bar and passes 600 l/min at connection G 1/4". The switching function is centre position closed. The materials are body and spool aluminium, seals NBR, pilot polyamide.
Advantages
- Flow rate of 600 l/min, so the connected actuator moves without the valve throttling it.
- Switching function centre position closed, so the rest position is clearly defined.
- Nominal size of 3.9 mm, which defines the usable cross section of the switching position.
- Operating pressure of 1.5 to 8 bar, which fixes the permissible working range.
- Materials body and spool aluminium, seals NBR, pilot polyamide, matched to the intended service.
Applications
- Sequencing of pneumatic axes with connection G 1/4" in handling equipment.
- Control of pneumatic flaps, gates and diverters in conveying equipment.
- Cycled feeding and clamping units in fixture building.
- Plants operated within the temperature range -5 to +60 °C.
Technical data
| Feature | Value |
|---|---|
| Function | centre position closed |
| Switching function | 5/3-way |
| Thread G1 (3x) | G 1/4" |
| Exhaust thread G2 (2x) | G 1/8" |
| Pilot port thread G3 | 2x G 1/8" |
| Nominal diameter [mm] | 3.9 |
| Flow rate [l/min] | 600 |
| Dimensions [mm] | A 106.5, B 35, C 22, D 10.5, E 36, F 20, H1 4.3, H2 3.3, J 17, K 27, L 38, M 28, N 36, O 35.5, P 3, S 21, T 46, W 0 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide |
| Temperature range | -5 to +60 °C |
| Operating pressure | 1.5 to 8 bar |
| Pilot pressure | 2 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Service life | min. 40 million switching cycles |
| Weight | 0.185 kg |
| Manufacturer | E.MC |
| Hersteller-Nr | RV 5322-08C A |
| EAN | 4050571716332 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
