Three-dimensional gantry stroke X 400 mm Y 700 mm stepper motor EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN - Festo 8184926
The Festo three-dimensional gantry EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN moves loads with 400 mm stroke in X and 700 mm in Y, plus two Z axes with 200 mm and 200 mm stroke. Key data: speed up to 0.5 m/s, acceleration up to 1 m/s², repeatability ±0.1 mm.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo three-dimensional gantry EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN moves loads with 400 mm stroke in X and 700 mm in Y, plus two Z axes with 200 mm and 200 mm stroke. Speed up to 0.5 m/s, product weight 9.12 kg.
At a glance
- Speed up to 0.5 m/s
- Acceleration up to 1 m/s²
- Repeatability ±0.1 mm
- Stepper motors in microstep mode with more than 4000 steps per revolution
- Parameterisation via Ethernet, FTP and TCP/IP protocols
- Degree of protection IP10
Areas of use
The EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN suits light pick-and-place and loading tasks with process forces up to 15 N in Z direction. The controller uses linear interpolation and is parameterised via Ethernet (TCP/IP).
Technical data
| Order type | EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN |
|---|---|
| Festo part number | 8184926 |
| Size | 15 |
| Stroke of the X-axis | 400 mm |
| Stroke of the Y-axis | 700 mm |
| Stroke of the Z-axis 1 | 200 mm |
| Stroke of the Z-axis 2 | 200 mm |
| Controller operating mode | p position controller, direct mode, synchronised operating modes, homing, open-loop operation |
| Operating mode | microstepping, >4000 steps/rev |
| Adjustable current reduction | about software |
| Mounting position | horizontal |
| Protective function | voltage failure detection, software end-position detection |
| Design | three-dimensional gantry system |
| Type of interpolation | linear interpolation |
| Type of motor | stepper motor |
| Position mode | position directly transferred |
| Display | green/yellow/red LED |
| Nominal current setting | about software |
| Maximum acceleration | 1 m/s² |
| Maximum speed | 0.5 m/s |
| Repetition accuracy | ±0.1 mm |
| Maximum search speed X-axis | 0.03 m/s |
| Maximum creep speed X-axis | 0.003 m/s |
| Maximum search speed velocity Y-axis | 0.03 m/s |
| Maximum creep speed Y-axis | 0.003 m/s |
| Maximum search speed Z-axis | 0.015 m/s |
| Maximum creep speed Z-axis | 0.003 m/s |
| Duty cycle | 100% |
| Nominal voltage for logic power supply DC | 5 V |
| Nominal voltage load voltage DC | 24 V |
| Nominal voltage X-axis | 1.68 V |
| Nominal voltage Y-axis | 3.2 V |
| Nominal voltage Z-axis | 3.2 V |
| Nominal current X-axis | 4.2 A |
| Nominal current Y-axis | 2 A |
| Nominal current Z-axis | 2 A |
| Parameterisation interface | Ethernet |
| Position control | yes |
| Ethernet, supported protocols | FTP, TCP/IP |
| Permissible range for logic voltage | ±10% |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | to EU EMC Directive |
| UKCA marking (see declaration of conformity) | to UK instructions for EMC |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -10 to 60 °C |
| Relative air humidity | 0 - 90% |
| Sound pressure level | 65.8 dB(A) |
| Degree of protection | IP10 |
| Ambient temperature | 10 to 40 °C |
| Motor holding torque | 0.5 to 1.4 Nm |
| Maximum process force in Z direction | 15 N |
| Feed constant of the X-axis | 64 mm/U |
| Feed constant of the Y-axis | 37.7 mm/U |
| Feed constant of the Z-axis | 5 mm/U |
| Product weight | 9120 g |
| Process interfacing | Drives with positioning function |
| Communication interface, logic | Ethernet - TCP/IP |
| Type of mounting | with female thread M3 |
| Note on materials | RoHS compliant |
| Customs tariff number | 84798997 |
| Weight | 28 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EXCL-15-400-700-Z2-200-200-GF-ST-R-1-EK-M6-AN |
| EAN | 4052568631109 |
| Zolltarifnummer | 84798997 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Operating voltage | 24 V DC |
| Protection rating | IP10 |
| Temperature (max.) | 40 |
