Single-acting aluminum lock nut hydraulic cylinder delivering 218 kN over a 50 mm stroke. The lock nut holds the load mechanically, even if pressure drops, at about 4 kg.
Aluminum Lock Nut Hydraulic Cylinder, 218 kN, 50 mm Stroke - Enerpac RACL202
ENERPAC Original product
Net price (excl. VAT)
€1,608.90 €1,352.02
Item ENP-RACL202
Manufacturer no. RACL202
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.RACL202
Country of originUnited States
ConditionNeu
Artikel
ENP-RACL202
Frequently Bought Together
- This Item: €1,608.90 €1,352.02
- Aluminum Hollow Plunger Hydraulic Cylinder, 229 kN, 100 mm Stroke - Enerpac RACH204 €2,526.69 €2,123.27
- Pull Cylinder double-acting 14 kN 28 mm stroke - Enerpac PTSD121 €1,195.59 €1,004.70
The RACL202 lifts and supports loads with 218 kN over a 50 mm stroke and then secures the position mechanically. The aluminum lock nut holds the load for extended periods, independent of hydraulic pressure.
Benefits
- Aluminum lock nut for mechanical load holding over long periods
- Composite bearings prevent metal-to-metal contact and improve side-load capacity
- Integral stop ring limits plunger travel and withstands the full cylinder capacity
- Hard-anodized aluminum body at about half the weight of steel
- High-strength return spring, steel base plate and carrying handle as standard, CR400 coupler with dust cap
Technical data
- Capacity: 218 kN
- Stroke: 50 mm
- Operating pressure: 700 bar
- Type: single-acting, spring return
- Outside diameter: 85 mm
- Plunger thread (lock nut): Tr 55 x 4
- Lock nut height: 50 mm
- Base mounting thread: M6
- Weight: 4 kg
- Series: RACL
Standards
- Compliant with ASME B30.1
| Hersteller-Nr | RACL202 |
|---|---|
| Manufacturer | Enerpac |
| Country of Manufacture | United States |
| Weight | 4.000000 |
| Hinweis | Industriewerkzeuge |
| GPSR Herstellerdaten | Enerpac GmbH, Willstätterstraße 13, DE-40549 Düsseldorf, www.enerpac.com |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
| Serie | RACL |
| Kapazität (kN) | 100-250 kN |
