High Tonnage Hydraulic Cylinder, 1497 kN, 100 mm Stroke - Enerpac HCR1504

The HCR1504 handles extreme lifting and pressing forces with 1497 kN capacity over a 100 mm stroke. As a double-acting cylinder it advances and retracts hydraulically at speed, shortening cycle times.

Benefits

• Double-acting for fast hydraulic advance and retract
• Withstands up to 10 % side load across the full cylinder capacity
• Hardened surface resists side loading and cyclic wear
• Replaceable top and bottom bearings for stability throughout the stroke
• Certified lifting eyes and base mounting holes for safe handling and firm installation
• Weather protected design for indoor and outdoor use

Technical data

• Thrust: 1497 kN
• Stroke: 100 mm
• Type: double-acting, hydraulic return
• Operating pressure: 700 bar
• Collapsed height: 270 mm
• Extended height: 370 mm
• Outside diameter: 215 mm
• Weight: 67 kg
• Series: HCR

Applications

For heavy lifting, pressing and positioning tasks with high cycle demand in machinery, bridge and plant construction.
