550 kN Capacity, 150 mm Stroke, Single-Acting, High Tonnage Hydraulic Cylinder - Enerpac HCG506
Datasheet (PDF)
Pictures are for reference and may not be accurate, actual product may differ
HCG506, 550 kN Capacity, 150 mm Stroke, Single-Acting, High Tonnage Hydraulic Cylinder

550 kN Capacity, 150 mm Stroke, Single-Acting, High Tonnage Hydraulic Cylinder - Enerpac HCG506

ENERPAC Original product
Net price (excl. VAT)
€1,309.69 €1,100.58
excl. Shipping Cost
Available Fast shipping
Item ENP-HCG506
Manufacturer no. HCG506
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.HCG506
Country of originUnited States
ConditionNeu
Add to Wish List Add to Compare
Artikel
ENP-HCG506
Model: HCG506 |ECCN: EAR99 | Harmonization: 8412210075
Series: HCG |Product Line: Industrial Tools

  • Hardened surface resists side-loading and cyclic wear
  • 7% side-load resistance over full stroke
  • Stop-ring to prevent plunger blow-out
  • Weather protected, inside and out
  • Upper and lower replaceable bearings enclose the cylinder plunger for support throughout the stroke
  • Certified lifting eyes, base mounting holes and collar threads

Dimension imperial

Collapsed Height A (in)
11.14
Collapsed Height With Optional Tilt Saddle A1 (in)
11.69
Optional Tilt Saddle Addition To Collapsed Height A1 (in)
0.55
Optional Tilt Saddle Diameter J1 (in)
2.8
Extended Height B (in)
17.05
Outside Diameter D (in)
5.12
Cylinder Bore Diameter E (in)
3.94
Plunger Diameter F (in)
2.76
Base to Advance Port H (in)
1.5
Saddle Diameter J1 (in)
1.97
Saddle Protrusion from Plunger K (in)
0.12
Saddle Maximum Tilt Angle Radius (degrees)
5
Base Mounting Holes Thread V
M12 x 1,75
Collar Thread Size W
M130 x 2
Collar Thread Length X (in)
1.18

Dimension metric

Collapsed Height A (mm)
283
Collapsed Height With Optional Tilt Saddle A1 (mm)
297
Optional Tilt Saddle Addition To Collapsed Height A1 (mm)
14
Extended Height B (mm)
433
Outside Diameter D (mm)
130
Cylinder Bore Diameter E (mm)
100
Plunger Diameter F (mm)
70
Base to Advance Port H (mm)
38
Saddle Diameter J (mm)
50
Saddle Protrusion from Plunger K1 (mm)
3
Saddle Maximum Tilt Angle Radius (degrees)
5
Base Mounting Holes Bolt Circle U (mm)
105
Base Mounting Holes Thread V
M12 x 1,75
Collar Thread Size W
M130 x 2
Collar Thread Length X (mm)
30
Base Mounting Holes Thread Depth Z (mm)
22
More Information
Hersteller-Nr HCG506
Manufacturer Enerpac
Country of Manufacture United States
Weight 24.000000
Hinweis Industriewerkzeuge
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Originalprodukt
Artikelzustand Neu
