High Tonnage Ultra Flat Hydraulic Cylinder, 792 kN, 10 mm Stroke - Enerpac CUSP75

The CUSP75 delivers 792 kN of force in minimal space. With a collapsed height of just 60.5 mm and a 10 mm stroke, this ultra-flat hydraulic cylinder works where standard cylinders no longer fit.

Benefits

• Extremely low collapsed height of 60.5 mm for confined spaces
• Integrated tilting function up to 4 degrees distributes the load and limits side load to up to 4 percent of rated capacity
• Nitrocarburized surface for enhanced corrosion protection in harsh conditions
• Red warning line clearly indicates the maximum permissible stroke
• Coupler AR630 including dust cap for quick connection to the pump

Technical data

• Capacity: 792 kN
• Stroke: 10 mm
• Collapsed height: 60.5 mm
• Extended height: 70.5 mm
• Outside diameter: 150 mm
• Bore diameter: 120 mm
• Operating pressure: 700 bar
• Weight: 8 kg
• Series: CUSP

Applications

For high-tonnage lifting and pressing tasks in confined installation spaces. All ultra-flat cylinders require a solid, level bearing surface so the load is supported without settling.
