High Tonnage Ultra Flat Hydraulic Cylinder, 198 kN, 6 mm Stroke - Enerpac CUSP20

The CUSP20 is a high-tonnage flat cylinder delivering 198 kN of force over a 6 mm stroke at a collapsed height of only 40.5 mm. The integrated tilting function of up to 4 degrees distributes the load evenly and prevents side load.

Benefits

• Tilting saddle up to 4 degrees compensates for uneven surfaces and prevents side load
• Extremely low collapsed height of 40.5 mm for confined installations
• Red warning line clearly indicates the maximum permissible stroke
• Handles up to 4 % side load at full rated capacity
• Nitrocarburized surface for enhanced corrosion protection in harsh conditions
• Coupler AR630 with dust cap, connect to the pump with an HB7206 hose

Technical data

• Capacity: 198 kN
• Stroke: 6 mm
• Collapsed height: 40.5 mm
• Extended height: 46.5 mm
• Outside diameter: 90 mm
• Bore diameter: 60 mm
• Operating pressure: 700 bar
• Weight: 1.9 kg
• Series: CUSP

Applications

For high-capacity lifting and positioning tasks in confined spaces. The cylinder needs a solid, level bearing surface, as use on sand, mud or uneven ground can damage it.
