Ultra Flat Hydraulic Cylinder with Stop Ring, 97 kN, 6 mm Stroke - Enerpac CULP10
Ultra-flat hydraulic cylinder with 97 kN capacity and 6 mm stroke at just 27.5 mm collapsed height. The stop ring limits the stroke and protects the cylinder in tight spaces.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The CULP10 is an ultra-flat hydraulic cylinder delivering 97 kN of force over a 6 mm stroke, working in very tight spaces thanks to a collapsed height of only 27.5 mm. The stop ring limits maximum stroke and protects the cylinder from over-extension.
Benefits
- Extremely low collapsed height of 27.5 mm for confined installations
- Stop ring limits the stroke and prevents over-extension of the cylinder
- Handles up to 4 % side load at full rated capacity
- Nitrocarburized surface for enhanced corrosion protection in harsh conditions
- Coupler AR630 with dust cap, connect to the pump with an HB7206 hose
Applications
Suited to lifting and positioning tasks in confined spaces where conventional cylinders will not fit.
Technical data
| Capacity | 97 kN |
|---|---|
| Stroke | 6 mm |
| Collapsed height | 27.5 mm |
| Extended height | 33.5 mm |
| Outside diameter | 72 mm |
| Bore diameter | 42 mm |
| Operating pressure | 700 bar |
| Weight | 1 kg |
| Series | CULP |
| Manufacturer | Enerpac |
| Hersteller-Nr | CULP10 |
| Hinweis | Industriewerkzeuge |
| GPSR Herstellerdaten | Enerpac GmbH, Willstätterstraße 13, DE-40549 Düsseldorf, www.enerpac.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | United States |
| Kapazität, kN | up to 100 kN |
