Enerpac BRD46, 35 kN Capacity, 155 mm Stroke, Double-Acting, General Purpose Hydraulic Cylinder

ENERPAC Original product
Net price (excl. VAT)
€1,084.49 €911.34
excl. Shipping Cost
Available Fast shipping
Item ENP-BRD46
Manufacturer no. BRD46
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.BRD46
ConditionNeu
Add to Wish List Add to Compare
Artikel
ENP-BRD46
Enerpac BRD46, 35 kN Capacity, 155 mm Stroke, Double-Acting, General Purpose Hydraulic Cylinder
Pictures are for reference and may not be accurate, actual product may differ
BRD46, 35 kN Capacity, 155 mm Stroke, Double-Acting, General Purpose Hydraulic Cylinder
Frequently Bought Together
Model: BRD46 |ECCN: EAR99 | Harmonization: 8412210075
Series: BRD |Product Line: Industrial Tools, Workholding Tools

  • Designed for long life, the best choice for production applications
  • Unique mounting configurations simplify fixturing
  • Baked enamel finish for increased corrosion resistance
  • Double-acting operation develops force in both directions, providing maximum versatility
  • Plunger wiper reduces contamination, extending cylinder life

Dimension imperial

Collar Thread Size W
M42 x 1,5

Dimension metric

Collapsed Height A (mm)
313
Extended Height B (mm)
468
Body Length C (mm)
289
Outside Diameter D (mm)
50
Cylinder Bore Diameter E (mm)
25,4
Plunger Diameter F (mm)
19,0
Bottom to Advance Port I (mm)
47
Top to Retract Port H (mm)
47
Plunger Protrusion K (mm)
24
Clevis Eye Mounting Dimension L (mm)
385
Clevis Eye Mounting Dimension L1 (mm)
540
Clevis Eye Mounting Dimension M (mm)
41
Neck Length N (mm)
29
Plunger Thread Length P (mm)
22
Plunger External Thread Q (mm)
M16 x 1,5
Collar Thread Size W
M42 x 1,5
Collar Thread Length X (mm)
11
Internal Base Thread Z (mm)
M30 x 1,5
Internal Base Thread Length Z1 (mm)
9
More Information
Hersteller-Nr BRD46
Manufacturer Enerpac
Weight 3.600000
Size -
Hinweis Industriewerkzeuge, Spanntechnik
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Originalprodukt
Artikelzustand Neu
