Pull Hydraulic Cylinder, 110 kN, 150 mm Stroke - Enerpac BRP106L

The BRP106L pulls with 110 kN over a 150 mm stroke as a single-acting, spring-return pull cylinder. Its hard chrome-plated, high-strength alloy steel piston stands up to sustained pulling loads.

Benefits

• Single-acting with spring return for simple operation
• Hard chrome-plated piston for long life
• High-strength alloy steel body
• CR400 coupler with dust cap fitted as standard
• Plunger wiper and baked enamel finish resist dirt and corrosion

Technical data

• Pull force: 110 kN
• Stroke: 150 mm
• Operation: single-acting, spring return
• Operating pressure: 700 bar
• Bore diameter: 54.1 mm
• Outside diameter: 85 mm
• Collapsed height: 573 mm
• Extended height: 723 mm
• Weight: 13.3 kg
• Series: BRP
