Servo motor 690 W, 2.6 Nm standstill torque, multi-turn encoder EMMT-AS-80-M-HS-RM - Festo 5255438

Festo ✓ Original product Brand new

2.2 Nm nominal torque and 6.4 Nm peak torque make the EMMT-AS-80-M-HS-RM a drive for dynamic positioning tasks. Rated power 690 W at 3000 1/min, designed for 680 V DC. A multi-turn absolute encoder (EnDat 22) captures the rotor position.

Net
€846.92
excl. VAT
Item FES-5255438
Manufacturer no. EMMT-AS-80-M-HS-RM
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

2.2 Nm nominal torque at 3000 1/min: the Festo EMMT-AS-80-M-HS-RM servo motor delivers 690 W rated power to the axis. Total moment of inertia is 1.035 kgcm².

Benefits

  • Peak torque 6.4 Nm for short cycles and acceleration phases
  • Speed up to 6800 1/min, nominal speed 3000 1/min
  • Multi-turn absolute encoder with 4096 absolute revolutions, no homing run after power-up
  • Cogging torque below 1.0 % of peak torque, smooth running even at low speeds
  • Degree of protection IP40, ambient temperature -40 to 40 °C

Application

The EMMT-AS-80-M-HS-RM drives linear axes, spindles and gear units. Permitted radial shaft load is 620 N.

Technical data

TypeEMMT-AS-80-M-HS-RM
Festo part no.5255438
Weight3 kg
Ambient temperature-40 to 40 °C
Note on ambient temperatureUp to 80°C with derating of -1.5% per degree Celsius
Maximum installation height4000 m
Note on maximum installation heightAs of 1,000 m: only with derating of -1.0% per 100 m
Storage temperature-40 to 70 °C
Relative air humidity0 - 90%
Conforms to standardIEC 60034
Temperature class as per EN 60034-1F
Maximum winding temperature155 °C
Rating class as per EN 60034-1S1
Temperature monitoringDigital motor temperature transmission via EnDat® 2.2
Motor type to EN 60034-7IM V1, IM V3
Mounting positionAny
Degree of protectionIP40
Note on degree of protectionIP67 for motor housing including connection components
Concentricity, coaxiality, axial runout to DIN SPEC 42955N
Balance qualityG 2.5
Detent torque&lt,1.0% of peak torque
Bearing lifetime under nominal conditions20000 h
Interface code, motor out80P
Electrical connection 1, connection typeHybrid plug
Electrical connection 1, connector systemM23x1
Electrical connection 1, number of connections/cores15
Electrical connection 1, connection pattern00995913
Pollution degree2
Note on materialsRoHS compliant
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Vibration resistanceTransport application test with severity level 2 to FN 942017-4 and EN 60068-2-6
Shock resistanceShock test with severity level 2 to FN 942017-5 and EN 60068-2-27
ApprovalRCM, c UL us - Recognized (OL)
CE mark (see declaration of conformity)To EU EMC Directive, To EU Low Voltage Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions, To UK regulations for electrical equipment
Certificate issuing authorityUL E342973
Nominal operating voltage DC680 V
Type of winding switchStar inside
Number of pole pairs5
Standstill torque2.6 Nm
Nominal torque2.2 Nm
Peak torque6.4 Nm
Nominal rotary speed3000 1/min
Maximum rotational speed6800 1/min
Maximum mechanical speed14000 1/min
Angular acceleration100000 rad/s²
Nominal power rating of motor690 W
Continuous stall current2.6 A
Nominal motor current2.2 A
Peak current9 A
Motor constant1 Nm/A
Standstill torque constant1.17 Nm/A
Voltage constant, phase-to-phase70.7 mVmin
Phase-phase winding resistance7.43 Ohm
Phase-phase winding inductance31.8 mH
Winding longitudinal inductivity Ld (phase)19.4 mH
Winding cross inductivity Lq (phase)23.8 mH
Electric time constant6.4 ms
Thermal time constant45 min
Thermal resistance0.78 K/W
Measuring flange250 x 250 x 15 mm, steel
Total mass moment of inertia of output1.035 kgcm²
Product weight2640 g
Permissible axial shaft load120 N
Permissible radial shaft load620 N
Rotor position sensorAbsolute encoder, multi-turn
Rotor position sensor, manufacturer designationEQI 1131
Rotor position sensor, absolute detectable revolutions4096
Rotor position encoder interfaceEnDat 22
Rotor position sensor, encoder measuring principleInductive
Rotor position sensor, DC operating voltage5 V
Rotor position sensor, DC operating voltage range3.6 to 14 V
Rotor position sensor, position values per revolution524288
Rotor position transducer resolution19 bit
Rotor position sensor, system accuracy of angle measurement-120 to 120 arcsec
Mean time to failure (MTTF), subcomponent190 years, rotor position encoder
Energy efficiencyENEFF (CN) / Class 2
ManufacturerFesto
Hersteller-NrEMMT-AS-80-M-HS-RM
EAN4052568460396
Zolltarifnummer85015100
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
AusführungMultiturn-Absolutwertgeber, ohne Haltebremse
NormDIN EN 60034-1, DIN EN 60034-7, DIN EN 60034
SeriesEMMT
Protection ratingIP40
Temperature (max.)40
