Adjustable cutting ring fitting, thread M 12x1.5, tube stud 6 S, stainless steel 1.4571
With the adjustable cutting ring fitting the joint is made at one point, the male thread M 12x1.5 meets a tube stud 6 S. Tube stud 6 S, material stainless steel 1.4571, operating pressure up to 630 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The operating pressure reaches up to 630 bar. The adjustable cutting ring fitting connects the male thread M 12x1.5 and a tube stud 6 S in doing so.
Benefits
- The material stainless steel 1.4571 stays resistant without additional coating in the range from -20 °C to +200 °C
- The heavy series with the code S follows the dimension series to ISO 8434-1
- The cutting ring bites into the tube wall and holds the tube even under pressure surges
- The connection over male thread M 12x1.5 is fixed in size and needs no adaptor
- With tube stud 6 S the size is fixed, so no reworking of the line is required
Applications
Hydraulic lines in machine and plant engineering, pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction.
Standards and conformity
The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
Technical data
| Material | 1.4571 |
|---|---|
| Series | heavy series S |
| Tube stud diameter | 6 S |
| Male thread | M 12x1.5 |
| Operating pressure | 630 bar |
| Temperature range | -20 to +200 °C |
| Weight | 0.045000 |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | EVGE 6 SM ES |
| EAN | 4050571287788 |
| Zolltarifnummer | 73071990 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Einschraubgewinde | M 12x1,5 |
| Rohrstutzendurchmesser [mm] | 6 S |
| Norm | DIN 2353, ISO 8434-1 |
| Series | schwere Baureihe |
| Temperaturbereich | -20-200 °C |
